In addition to the codes configured at the desktop, some codes are generated automatically when
the agent is logged out by the software. the table below describes these predefined Logout
Reason codes.
Note: Check your ACD Supplement Guide to make sure that Agent Logout Reasons codes are
supported for your ACD.
See also:
Configuring Agent Logout Reason Codes (page 192)
DescriptionPredefined Logout Reason Code
The agent reinitialized due to peripheral restart.-1
The PG reset the agent, normally due to a PG failure.-2
An administrator modified the agent's extension while
the agent was logged in.
-3
A CTI OS component failed, causing the agent to be
logged out. This could be due to closing the agent
50002
desktop application, heartbeat time out, a CTI OS
Server failure, or a CTI OS failure.
The agent was logged out because the ACD reported
the agent's device as out of service.
50003
The agent was logged out due to agent inactivity as
configured in agent desk settings.
50004
The agent was logged out when his/her skill group
assignment dynamically changed on the AW.
50020
The agent's state was changed to NOT READY.20001 - applicable if you are using the
Cisco Agent Desktop
A normal log out condition from NOT READY20002 - applicable if you are using the
Cisco Agent Desktop
Forces the logout request.20003 - applicable if you are using the
Cisco Agent Desktop
Reports that show Agent Logout Reason Codes
These are some reports that contain information on Agent Logout reason codes:
•
agent03: Agent Media Status Logout Report
•
agteam03: Agent Team Media Status Logout Report
Reporting Guide for Cisco Unified ICM Enterprise & Hosted Release 7.2(1)
86
Chapter 5: Reporting on Agents
Reporting on Agent Logout Reason Codes
