Description for Multi-session Chat
MRD
Description for all MRDs except
Multi-session Chat
State in Skill Group
Work Ready, Reserved, or Paused in
another skill group in the same MRD.
The agent is not working on any task
or call associated with this skill group.
The agent is not working on any task
or call associated with this skill group.
Not Active
The agent is not available to be
assigned a task. If an agent is Not
The agent is not available to be
assigned a task. If an agent is Not
Not Ready
Ready in one skill group, the agent isReady in one skill group, the agent is
Not Ready in all skill groups within the
same Media Routing Domain.
Not Ready in all skill groups within the
same Media Routing Domain.
Agent States and Skill Groups
Agents can belong to multiple skill groups in a Media Routing Domain. When an agent is
handling a task that was routed to a skill group, the agent is Active in that skill group.
For Unified ICM routed calls or transferred Unified ICM-routed calls that use the dialed number,
the active skill group is the skill group to which the task was queued.
For direct incoming calls or transferred routed calls on the ACD, the active skill group is the
first skill group defined for the agent or the skill group assigned by the ACD.
For new outgoing calls (AgentOutCalls or InternalCalls) or transferred outbound calls, the active
skill group is either the ACD-picked skill group or the first skill group defined for the agent.
If you are reporting on agents who handle multi-session chat tasks (and who can work on more
than one task at a time), gather agent state information from both the Available in MRD and
Agent State columns.
The agents' state in the active skill group dictates their state in other skill groups in the Media
Routing Domain to which they belong, as follows:
•
If the agent is Active, Work Ready, Reserved, or Hold/Paused in one skill group in the MRD,
the agent state is Busy Other for all other skill groups in the MRD.
•
If the agent is Not Ready in one skill group in the MRD, the agent is Not Ready in all skill
groups in the MRD.
See also Reporting in a MultiChannel Environment (page 127).
The Role of Default Skill Group in Reporting
The default skill group acts as a bucket to capture information about voice calls not routed by
ICM routing scripts or if a skill group is not specified in a routing script. A default skill group
captures call statistics for calls that are not routed by an ICM routing script. For example, if the
Agent to Agent node is used in a routing script for agent to agent dialing, data is gathered for
the default skill group.
