Configured entities are stored as records in database tables. For Unified ICM Configuration,
entities include agents, Call Types, dialed numbers, labels, routes, translation routes, trunks,
trunk groups, and network trunk groups, services and service members, skill groups, peripheral
monitors, and targets.
See Configured Entities that Capture Reporting Data (page 185) for the full list of the entities.
Configuration data are stored in the Central Controller database. When you apply a change to
the Configuration Manager, it is immediately applied to the Central Database on the Logger
and copied to all local AW databases.
Also see Appendix C (page 189) for configuration procedures relevant to reporting.
Configuration on the ACD
Not all Unified ICM Configuration entities are supported on all ACDs.
For all Peripheral Gateway types per ACD type that Cisco supports, there is a published ACD
Supplement document. You can find these ACD Supplements on www.cisco.com (http://
www.cisco.com) under Technical Support and Documentation.
To the extent that configurations do correlate, it is critical to match them exactly.
Please read the appropriate ACD Supplement Guide to ensure that the configuration settings on
the ACD operate properly with the Unified ICM software.
ACD Supplement guides provide the following information:
•
Unified ICM features that the ACD does, and does not, support
•
The ACD Configuration
•
Unified ICM Configuration with respect to the specific ACD
•
Any configuration and scripting issues you need to be aware of
•
Reporting caveats specific to the ACD
The ACD Supplement Guides direct you to make configuration changes other than deletions on
the ACD first, and then in Configuration Manager. This ensures that the PG is aware of the
updates.
For deletions, first remove the references to those objects in Unified ICM, then delete the objects
from the ACD. This ensures that the deleted objects are not used in routing decisions.
If you make configuration changes on the ACD, make sure they are reflected in the Unified
ICM. For example, if you configure a new agent, skill group, or route on the ACD, make a
corresponding change in Configuration Manager.
