Reporting Considerations
In order to get accurate and useful reporting metrics in this type of deployment, it is important
to consider several factors that affect reporting as discussed in the reporting consideration
sections for Enterprise Routing (page 45) and for Agent Level Routing (page 52).
Some of these factors include:
•
Two reporting models used to provide reporting statistics for the application: Services are
used for Enterprise Routing and Call Types for Agent Level Routing.
•
The use of a Service Control VRU in your deployment to provide initial call treatment and
enterprise queuing when sharing queues (skill groups) across call centers. This entails queuing
calls to skill groups waiting for an available agent across your enterprise.
•
The reporting on queuing statistics—ACD queues and Enterprise queues.
•
The use of the Translation Routing mechanism to route calls to legacy ACDs for enterprise
routing. This allows for call types to be used to provide reporting statistics for the application
(Cradle to Grave). Translation Routing is implicit with Agent Level Routing.
•
Routing scripts set up for your call center operations.
The table below defines the report categories to use to meet the reporting needs for your
enterprise.
Enterprise Reporting
•
Use Call Type reports (page 172) for an enterprise view of reporting statistics for the
application, including queue statistics.
•
Use Enterprise Skill Group reports (page 179) for an enterprise view of reporting statistics
when calls are routed to a particular skill group, including queue statistics.
Key StatisticsReport CategoryReporting Statistics
Needed
Report focus
Number of calls routed.Call TypeBefore call is routed to an
agent
Application
Number of calls received.
Number of calls that
encountered an error.
Queue Statistics and
Abandons.
AbandonsCall TypeAfter call is routed to an
agent
Service Level
