3. The script uses the LAA (longest available agent) node to look for an available agent
across the enterprise who can handle the call.
Once an available agent is found across the two call centers, Unified ICM selects the agent
and provides instructions to the routing client to direct the call to the agent.
4. If an agent is not available, the script instructs the Unified ICM software to translation
route the call to the VRU and queue the call.
5. When an agent becomes available, Unified ICM selects the agent and provides instructions
to the routing client (VRU) to direct the call to the agent.
Reporting Considerations
In this deployment, all queued calls are controlled by Unified ICM (Enterprise queue) and all
calls are translation routed.
The table below defines the report categories to use to meet the reporting needs for your
enterprise.
Enterprise Reporting
•
Use Call Type reports (page 172) for an enterprise view of reporting statistics for the
application, including queue statistics.
•
Use Enterprise Skill Group reports (page 179) for an enterprise view of reporting statistics
when calls are routed to a particular skill group, including queue statistics.
Key StatisticsReport CategoryReporting Statistics
Needed
Report focus
Number of calls routed.Call TypeBefore call is routed to an
agent
Application
Number of calls received.
Number of calls that
encountered an error.
Queue Statistics and
Abandons.
AbandonsCall TypeAfter call is routed to an
agent
Service Level
Redirection on No Answer
(RONA)
ASACall TypeAfter call is answered by an
agent
Calls Handled
Reporting Guide for Cisco Unified ICM Enterprise & Hosted Release 7.2(1)
52
Chapter 3: Understanding Routing and Queuing
Deployments with Agent Level Routing
