DescriptionHistorical or
Real-Time
Template Name
Table that shows all skill groups and their associated
Outbound Option Stats.
Rperskg11: Outbound Option (Blended
Agent) Statistics
Table of real time Peripheral Skill Group StatisticsRperskg20: ICM Peripheral Skill Group
Status Real Time
Table of all fields Skill Group Real Time StatisticsRperskg28: Peripheral Skill Group Real
Time All Fields
Table of Logout Real Time Statistics for Skill GroupRperskg29: Peripheral Skill Group
Logout Real Time
Table of half-hour FTE counts for agents signed on, idle,
available, talking, and in wrap-up.
Hperskg08: FTE for Peripheral Skill
Groups Half Hour
Stacked bar graph showing a normalized percentage of
agent-states over specified range of time.
Hperskg09: Peripheral Skill Group
Normalized Agent State
Table of half-hour outbound option counts for agents signed
on, handle, talk and hold.
Hperskg12: Outbound Option (Blended
Agent) Call Detail Performance in
Skill Groups Half Hour
Table of Call Statistics for Peripheral Skill Group by Half
Hour
Hperskg21: ICM Peripheral Skill Group
Task Summary Half Hour
Table of Call Statistics for Peripheral Skill Group by DayHperskg22: ICM Peripheral Skill Group
Task Summary Daily
Table of Peripheral Skill Group Statistics by Half HourHperskg23: ICM Peripheral Skill Group
Performance Summary Half Hour
Table of Peripheral Skill Group Statistics by DayHperskg24: ICM Peripheral Skill Group
Performance Summary Daily
Table of Consolidated Call and Skill Group Statistics by Half
Hour
Hperskg25: ICM Peripheral Skill Group
Consolidated Half Hour
Table of Consolidated Call and Skill Group Statistics by DayHperskg26: ICM Peripheral Skill Group
Consolidated Daily
Table of all fields for Skill Group by Half HourHperskg27: Peripheral Skill Group
Historical All Fields
Enterprise
An enterprise skill group is a collection of peripheral skill groups. They can be from the same
contact center or from several contact centers. All enterprise skill group tabular reports have
drill-down reports available.
DescriptionHistorical or
Real-Time
Template Name
Stacked bar graph showing numbers of agents in talking,
idle, available, and wrap-up states.
Rentskg01: Enterprise Skill Group
Status Real Time
Stacked bar graph showing the percentage of agents in
available, idle, talking, and wrap-up states.
Rentskg03: Enterprise Skill Group
Agent State Status
Reporting Guide for Cisco Unified ICM Enterprise & Hosted Release 7.2(1)
179
List of All Unified ICM Report Templates
Skill Group Templates
