DescriptionHistorical or
Real-Time
Template Name
Overlapped bar graph showing the distribution (number) of
tasks offered at a half-hour sample rate.
Hentsvc17: Enterprise Service Tasks
Offered Half Hour
Table report that shows historical task handling data for a
collection of gates.
Hentsvc18: Enterprise Gate Analysis
Half Hour
Table summary of all historical enterprise service fieldsHentsvc24: Enterprise Service Historical
All Fields
Peripheral
DescriptionHistorical or
Real-Time
Template Name
Bar graph of time (in seconds) for delays in queue, longest
task in queue, and ASA over last 5 minutes.
Rpersvc01: Peripheral Service Queue
Delay Status Real Time
Stacked bar graph of the number of tasks on which agents
are talking and the number of tasks in queue.
Hpersvc02: Peripheral Service Status
Real Time
Table of tasks offered, handled, abandoned, and the effect
of abandoned tasks on service levels.
Rpersvc03: Effect of Abandoned Tasks
on Peripheral Service Levels
Table of task counts and service levels (since end of last
5-minute and half-hour intervals, and since midnight).
Rpersvc04: Peripheral Service Tasks
Trend Analysis Real Time
Pie chart of the percentage distribution of tasks offered since
the end of the last half-hour interval.
Rpersvc05: Peripheral Service Tasks
Offered Over Half Hour
Bar graph of service levels since the end of the last 5-minute
and half-hour intervals, and since midnight. persvc07:
Rpersvc06: Peripheral Service Levels
Real Time
Peripheral Service Tasks, Averages and Service Levels Real
Time
Table that shows tasks and queue status in real-time where
service/skill group mapping is available.
Rpersvc08: Task and Agent Status Real
Time
Table summary of all real time peripheral service fields.Rpersvc27: Peripheral Service Real
Time All Fields
Overlapped bar graph that shows the number of tasks offered
per day.
Hpersvc13: Peripheral Service Tasks
Offered Daily
Overlapped bar graph that shows the number of tasks handled
per day.
Hpersvc14: Peripheral Service Tasks
Handled Daily
Overlapped bar graph that shows the number of tasks
abandoned per day.
Hpersvc15: Peripheral Service Tasks
Abandoned Daily
Line graph of tasks abandoned, handled, and offered per day
(for use with a single peripheral service).
Hpersvc16: Peripheral Service History
Daily
Overlapped bar graph showing the distribution (number) of
tasks offered at a half-hour sample rate.
Hpersvc17: Peripheral Service Tasks
Offered Half Hour
Table that shows half-hour status information for a Rockwell
Galaxy gate (ICM peripheral service).
Hpersvc18: Peripheral Gate Analysis
Half Hour
Reporting Guide for Cisco Unified ICM Enterprise & Hosted Release 7.2(1)
176
List of All Unified ICM Report Templates
Service Templates
