DescriptionHistorical or
Real-Time
Template Name
number of calls closed, number of customers contacted and
the number of calls abandoned by the agent and abandoned
to IVR in a campaign for the selected time period for
Outbound Option campaigns. This report combines the
campaign data with skill group data to show how the calls
are being treated for this campaign.
Table that shows the breakdown of completed calls (outbound
calls, inbound calls and/or calls transferred to the campaign's
Hcamqry22/23: Campaign Consolidated
Detailed Half Hour Report/Daily
Report skill group) for the selected campaigns and their skill groups
for the selected time period.
Dialer and Dialer Port
DescriptionHistorical or
Real-Time
Template Name
Table that shows contacts, busy, voice, answer machine,
SITTone, detects for each dialer.
Rdialer01: Dialer Real Time
Table by half hour that shows contacts, busy, voice, answer
machine, SITTone, detects for each dialer.
Hdialer10: Status of each Dialer Half
Hour
Table that shows dialer activity on a port by port basisRdialpr01: Dialer Port Status Real Time
Call Type Templates
These reports show statistics for the Call Types defined in the system.
DescriptionHistorical or
Real-Time
Report Name
Table that shows routing and script data on Call Types defined
in the system.
Rcaltyp01: Call Type Status
Stacked bar graph that tracks busy and default routed calls for
Call Types for the current day.
Rcaltyp02: Call Type Counts
Bar graph of service levels since the end of last 5 minute and
half-hour intervals, and since midnight.
Rcaltyp04: Call Type Service Levels
Table summary of Call Type real time fields.Rcaltyp20: Call Type Real Time
Table summary of all real time fields.Rcaltyp24: Call Type Real Time All
Fields
Stacked Bar Graph of the number of tasks in queue within
service level and tasks in queue outside service level.
Rcaltyp25: Call Type Queue Status
Bar chart of tasks offered to CallTypes since the end of the last
half-hour interval.
Rcaltyp26: Call Type Tasks Offered
Over Half Hour
Bar graph of time (in seconds) for average delay in queue,
longest call in queue, and ASA over last 5 minutes.
Rcaltyp27: Call Type Queue Delay
Status Real Time
Reporting Guide for Cisco Unified ICM Enterprise & Hosted Release 7.2(1)
172
List of All Unified ICM Report Templates
Call Type Templates
