Table 21: Agent State Before and After Peripheral Gateway/CTI Manager Service Fail-over
Agent State after Fail-overAgent State at Fail-Over
AvailableAvailable
Not ReadyNot Ready
Available, if in Available state before the call. Otherwise,
the agent reverts to Not Ready.
Wrap-up
Agent Desktop/CTI OS Server Fail-over
If the agent desktop (CTI OS or Cisco Agent Desktop) shuts down or loses communication with
CTI OS Server, or if the CTI OS Server shuts down, the agent is logged out of all Media Routing
Domains supported by the peripheral that has lost communication with Unified ICM software.
The agent is logged in again automatically when one of the following occurs:
•
The agent desktop comes back up or resumes communication with CTI OS Server
•
The agent is connected to the backup CTI OS server
The agent Media Logout Status reports for the agent, agent skill group, agent team, and agent
peripheral show a logout reason code of 50002.
The state to which the agent reverts after fail-over depends on the agent's state when the fail-over
occurred, as described in the following table.
Table 22: Agent State Before and After Agent Desktop/CTI OS Server Fail-over
Agent State after Fail-overAgent State at Fail-Over
AvailableAvailable
Not ReadyNot Ready
AvailableReserved
Available, if in Available state before the call. Otherwise,
the agent reverts to Not Ready.
Wrap-up
Reporting Guide for Cisco Unified ICM Enterprise & Hosted Release 7.2(1)
149
Chapter 10: Reporting Implications of Data Loss and Component Failover
Other Possible Points of Failover
