Table 8: Scenario 2: Not Routable - Voice then E-Mail
ResultScenario
Unified ICM does not assign e-mail tasks to the agent. The agent is Not
Available in the e-mail MRD.
The agent is logged into two MRDs,
multi-session chat and voice.
E-mail tasks can still be placed in the agent's personal queue in this
scenario by the E-Mail Manager Option. E-mail tasks might also be sent
The agent is not routable in the e-mail MRD.
The agent is assigned a call in the Voice MRD.
to the agent's queue as a result of a customer responding to an E-Mail
from the agent. See Cisco E-Mail Manager documentation for complete
information on routing E-Mail tasks.
Table 9: Scenario 3: Not Routable - Voice then Single-session Chat
ResultScenario
Web Collaboration Option does not assign
single-session chat tasks to the agent. The agent is Not
Available in single-session chat.
The agent is logged into two MRDs, single-session chat and
voice.
The agent is not routable in the single-session chat MRD.
The agent is assigned a call in the Voice MRD.
Table 10: Scenario 4: Routable - Maximum task limit
ResultScenario
Unified ICM continues to assign tasks to the agent until
the agent has reached his maximum task limit. The agent
The agent is logged into a multi-session chat MRD
(maximum task limit for the agent in this MRD is 6).
is ICM Available in the multi-session chat MRD, even
though the agent is Active on a task.
The agent is routable in the multi-session chat MRD.
The agent is assigned a task in the multi-session chat MRD.
Table 11: Scenario 5: Routable (busy on non-interruptible task)
ResultScenario
Unified ICM does not assign a multi-session chat task to the agent,
since the agent is working on a non-interruptible task in the voice
The agent is logged into two MRDs, multi-session
chat and voice.
MRD. The agent is Not Available in the multi-session chat MRD
The agent is routable in the multi-session chat MRD.
even though the agent is Not Active in multi-session chat skill
groups.
The agent is assigned a voice call in the voice MRD.
Reporting Guide for Cisco Unified ICM Enterprise & Hosted Release 7.2(1)
131
Chapter 8: Reporting in a MultiChannel Environment
Agent Availability and Routability
