DescriptionTerm
Unified ICM is configured to assign tasks to the agentRoutable
The Web Collaboration Option or E-Mail Manager Option is
configured the assign tasks to the agent.
Not Routable
While Routability determines whether the Router is allowed to assign tasks for this MRD, the
agent's Availability determines whether the agent is capable of handling new tasks.
An agent is Available, or eligible to be assigned a task in an MRD, if he or she meets all of
these conditions:
•
Is in any state other than Not Ready state for this MRD.
•
Is not working on a non-interruptible task in another MRD. Only e-mail tasks are interruptible,
meaning that Unified ICM can assign the agent another task while he is working on an e-mail.
Voice calls, single-session chat sessions, multi-session chat sessions, and Blended
Collaboration chat sessions cannot be interrupted.
•
Has not reached the maximum task limit for this MRD. For voice, single-session chat, e-mail
and Blended Collaboration MRDs, the task limit is always one task. For the multi-session
chat MRD, the task limit is customized through the Web Collaboration Option administration
application.
An agent is Not Available in an MRD if the agent is Not Ready, working on a voice,
single-session chat, multi-session chat, or e-mail task, or has reached his or her maximum task
limit.
Therefore, an agent is:
•
ICM available if he is Routable and Available for the MRD. This means that the agent can
be routed a task by Unified ICM.
•
Application available if he is Not Routable and Available for the MRD. This means that the
agent can be routed a task by the Web Collaboration Option or E-Mail Manager.
Consider the following call/task scenarios and how they affect agent mode and availability.
Table 7: Scenario 1: Not Routable - Multi-session Chat, then Voice
ResultScenario
Unified ICM does not assign a task to the agent from the
Voice MRD, since the agent is working on a
The agent is logged into two MRDs, multi-session chat and
voice.
non-interruptible task in the Multi-session Chat MRD.
The agent is Not Available in Voice.
The agent is not routable in the multi-session chat MRD.
The agent is assigned a task in the multi-session chat MRD
by the Web Collaboration Option.
