Dispersion Penalty at 100 km 3 dB Data rate above 2000 Mbps
Table 5. CWDM SFP Optical Specification (OC-3/STM-1)
Parameter Symbol Minimum Maximum Units Notes and Conditions
Transmitter Center Wavelength λ (λ–4) (λ + 7) nm Available center wavelengths are
1470, 1490, 1510, 1530, 1550,
1570, 1590, and 1610 nm
Transmitter Optical Output Power
Pout 0 5.0 dBm Average power coupled into
single-mode fiber
Receiver Optical Input Power
(BER <10–12 with PRBS 2–7—1)
Pin –34.0 –7.0 dBm at 155 Mbps
Receiver Optical Input
Wavelength
λ 1450 1620 nm
Dispersion Penalty at 100 km 1 dB at 155 Mbps
Table 6. DWDM SFP Optical Specification (OC-3/STM-4, OC-48/STM-16, 1G Ethernet, 1G Fiber Channel
and 2G Fiber Channel)
Parameter Symbol Minimum Maximum Units Notes and Conditions
Transmitter
Spectral Width 0.2 nm Full width, –20dB from
maximum, with resolution
bandwidth (RBW) = 0.01 nm
Transmitter Center Wavelength λ λ – 100 λ + 100 pm Center wavelengths are in-line
with Cisco DWDM channel plan
and 100GHz ITU grid
Side-Mode Suppression Ratio SMSR 30 dB
Transmitter Extinction Ratio OMI 8.2 dB
Transmitter Optical Output Power
Pout 0 4.0 dBm Average power coupled into
single-mode fiber
Receiver
Receiver Optical Input
Wavelength
λ 1530 1565 nm
Receiver Damage Threshold –1 dBm
Dispersion Tolerance –500 1600 ps/nm
Power-Limited Performance at OSNR of 20 dB (< 2000 Mbps) or 21 dB (> 2000 Mbps) at 0.1-nm RBW
Optical Input Power Pin –28.0 –9.0 dBm
Dispersion Power Penalty < 2000
Mbps
3 dB –800/+3600 ps/nm
Dispersion Power Penalty > 2000
Mbps
3 dB –800/+2400 ps/nm
Noise-Limited Performance at OSNR of 18 dB (< 2000 Mbps) or 19 dB (> 2000 Mbps) at 0.1-nm RBW
Optical Input Power Pin –22.0 –9.0 dB
Dispersion OSNR Penalty < 2000
Mbps
2 dB -800/+3600 ps/nm
Dispersion OSNR Penalty > 2000
Mbps
3 -800/+2400 ps/nm
Ordering Information
To place an order, visit the Cisco ordering homepage. Table 7 lists ordering information for the
Cisco 2-Channel SFP WDM Transponder.
Table 7. Ordering Information
Product Name Part Number
