DCD=up DSR=up DTR=up RTS=up CTS=up
Traffic sent by 819 LTE Interface: QoS Specifics
C819VZ-XL#spc (“spc” is an alias that expands to “show policy-map int cell0 out”
Cellular0
Service-policy output: LTE-SHAPER
Class-map: class-default (match-any)
72629 packets, 39623223 bytes
30 second offered rate 1643000 bps, drop rate 148000 bps
Match: any
Queueing
queue limit 64 packets
(queue depth/total drops/no-buffer drops) 42/1583/0
(pkts output/bytes output) 71046/37498130
shape (average) cir 1500000, bc 6000, be 6000
target shape rate 1500000
Service-policy : PNTM-A
queue stats for all priority classes:
Queueing
queue limit 64 packets
(queue depth/total drops/no-buffer drops) 0/0/0
(pkts output/bytes output) 49592/11108608
Class-map: CS5-EF (match-any)
49592 packets, 11108608 bytes
30 second offered rate 89000 bps, drop rate 0000 bps
Match: ip precedence 5
49592 packets, 11108608 bytes
30 second rate 89000 bps
Priority: 100 kbps, burst bytes 2500, b/w exceed drops: 0
Class-map: CS3-4 (match-any)
4321 packets, 5463327 bytes
30 second offered rate 311000 bps, drop rate 0000 bps
Match: ip precedence 3 4
4225 packets, 5449119 bytes
30 second rate 311000 bps
Match: access-group 105
96 packets, 14208 bytes
30 second rate 0 bps
Queueing
queue limit 64 packets
(queue depth/total drops/no-buffer drops) 0/0/0
(pkts output/bytes output) 4321/5463327
bandwidth 400 kbps
shape (average) cir 400000, bc 1600, be 1600
target shape rate 400000
Service-policy : SUB-CLASS-34
Class-map: PREC-3 (match-any)
4225 packets, 5449119 bytes
30 second offered rate 311000 bps, drop rate 0000 bps
Match: ip precedence 3
4225 packets, 5449119 bytes
30 second rate 311000 bps
Queueing
