Operation and Show Commands
ISR 819 QoS policy:
- 3 level, total shaper to 1.5 Mbps, 0.5 Mbps service rate,
- 100 Kbps strict priority (EF), 400 Kbps AF3x/AF4x/CS3/CS4)
- At least 250 Kbps for CS4/AF4x, 150 Kbps for CS3/AF3x
Traffic sent through 819:
- ~90 Kbps voice, ~300 Kbps CS3, ~1.2Mbps best effort
Traffic sent to ISR 819 VLAN Interface:
C819VZ-XL#siv (“siv” is a configured alias that expands to “show int vlan1”)
Vlan1 is up, line protocol is up
Hardware is EtherSVI, address is bcc4.93da.3448 (bia bcc4.93da.3448)
Internet address is 10.250.2.1/24
MTU 1500 bytes, BW 100000 Kbit/sec, DLY 100 usec,
reliability 255/255, txload 1/255, rxload 4/255
Encapsulation ARPA, loopback not set
Keepalive not supported
ARP type: ARPA, ARP Timeout 04:00:00
Last input 00:00:08, output never, output hang never
Last clearing of "show interface" counters never
Input queue: 0/75/0/0 (size/max/drops/flushes); Total output drops: 0
Queueing strategy: fifo
Output queue: 0/40 (size/max)
30 second input rate 1602000 bits/sec, 194 packets/sec
30 second output rate 85000 bits/sec, 50 packets/sec
73227 packets input, 37647211 bytes, 0 no buffer
Received 1006 broadcasts (27 IP multicasts)
0 runts, 0 giants, 0 throttles
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored
52232 packets output, 12161738 bytes, 0 underruns
0 output errors, 1 interface resets
424 unknown protocol drops
0 output buffer failures, 0 output buffers swapped out
Traffic sent by ISR 819 LTE Interface:
C819VZ-XL#sic (“sic” is a configured alias that expands to “show int cell0”)
Cellular0 is up, line protocol is up
Hardware is Cellular, Modem inserted
Internet address is 10.14.11.104/32
MTU 1500 bytes, BW 50000 Kbit/sec, DLY 100000 usec,
reliability 255/255, txload 7/255, rxload 1/255
Encapsulation SLIP, loopback not set
Keepalive not supported
Last input 00:00:00, output never, output hang never
Last clearing of "show interface" counters never
Input queue: 0/75/0/0 (size/max/drops/flushes); Total output drops: 1523
Queueing strategy: Class-based queueing
Output queue: 41/1000/1499 (size/max total/drops)
30 second input rate 89000 bits/sec, 50 packets/sec
30 second output rate 1475000 bits/sec, 180 packets/sec
52636 packets input, 12734332 bytes, 0 no buffer
Received 0 broadcasts (0 IP multicasts)
0 runts, 0 giants, 0 throttles
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
70294 packets output, 36627882 bytes, 0 underruns
0 output errors, 0 collisions, 1 interface resets
0 unknown protocol drops
0 output buffer failures, 0 output buffers swapped out
0 carrier transitions
