collocated single-tunnel
home-agent 66.174.251.2
mobile-network GigabitEthernet0/0/1
mobile-network GigabitEthernet0/0/0
non-connected-network 192.168.222.0 255.255.255.0
register extend expire 10 retry 3 interval 5
reverse-tunnel
tunnel mode gre
!
ip access-list extended CS3
permit ip host 10.250.1.12 any
ip access-list extended CS4
permit ip host 10.250.1.10 any
ip access-list extended CS5
permit ip host 10.250.1.11 any
!
access-list 105 permit udp any any eq mobile-ip
dialer watch-list 1 ip 5.6.7.8 0.0.0.0
dialer watch-list 1 delay route-check initial 60
dialer watch-list 1 delay connect 1
!
control-plane
!
alias exec spc show policy-map interface cell 0/1/0 out
alias exec sic show interface cell 0/1/0
alias exec sig show interface gi0/0/0
alias exec spg show policy-map interface gi0/0/0 in
!
line con 0
exec-timeout 0 0
login local
stopbits 1
line aux 0
stopbits 1
line vty 0 4
login local
!
!
end
*** Note that the ingress QoS policy on Gigabit Ethernet 0/0/0 (BCPS-IN) is configured to re-mark traffic for QoS
lab testing. For an organization’s production configuration, there may be no policy (marking may be done by
trusted devices or LAN switches) or a policy that integrates with an organization’s existing QoS design.
