ISR Configuration for LTE NIM (ISR 4K) – LTE QoS
!### IOS XE 3.16 or later ###
service internal
!
hostname C4321-4G
!
boot-start-marker
boot system bootflash:isr4300-universalk9.03.16.00.S.155-3.S-ext.SPA.bin
boot-end-marker
!
ip dhcp pool 10dot250dot1
network 10.250.1.0 255.255.255.0
default-router 10.250.1.1
dns-server 10.20.45.20
!
username cisco privilege 15 secret 5 xxxxxxxxxxxx
!
controller Cellular 0/1/0
!
class-map match-any CS5-EF
match ip precedence 5
class-map match-any PREC-3
match ip precedence 3
class-map match-all MARK-CS3
match access-group name CS3
class-map match-all MARK-CS4
match access-group name CS4
class-map match-all MARK-CS5
match access-group name CS5
class-map match-any PREC-4
match ip precedence 4
class-map match-any CS3-4
match ip precedence 3 4
match access-group 105
!
policy-map SUB-CLASS-34
class PREC-3
bandwidth 150
class PREC-4
bandwidth 250
policy-map PNTM-A
class CS5-EF
priority 100
class CS3-4
bandwidth remaining ratio 4
shape average 400000
service-policy SUB-CLASS-34
class class-default
bandwidth remaining ratio 10
fair-queue
random-detect dscp-based
policy-map LTE-SHAPER
class class-default
shape average 1500000
service-policy PNTM-A
