Chapter 2 Common Control Cards
2.4.1 XC-VXL-10G Functionality
2.4.1 XC-VXL-10G Functionality
The XC-VXL-10G card manages up to 192 bidirectional STM-1 cross-connects, 192 bidirectional E-3
or DS-3 cross-connects, or 1008 bidirectional E-1 cross-connects. The TCC2/TCC2P card assigns
bandwidth to each slot on a per-STM-1 basis. The XC-VXL-10G card works with the TCC2/TCC2P card
to maintain connections and set up cross-connects within the node. You can establish cross-connect and
provisioning information through CTC.
Note Cisco does not support operating the ONS 15454 SDH with only one XC-VXL-10G card. Always
operate in a redundant configuration. Install the XC-VXL-10G cards in Slots 8 and 10.
2.4.2 XC-VXL-10G Card-Level Indicators
Table 2-15 describes the two card-level LEDs on the XC-VXL-10G card faceplate.
2.5 XC-VXL-2.5G Card
Note For XC-VXL-2.5G card specifications, see the “A.4.4 XC-VXL-2.5G Card Specifications” section on
page A-12.
The XC-VXL-2.5G card cross-connects E-1, E-3, DS-3, STM-1, STM-4, STM-16, and STM-64 signal
rates. The XC-VXL-2.5G card provides a maximum of 192 x 192 VC-4 nonblocking cross-connections,
384 x 384 VC-3 nonblocking cross-connections, or 2016 x 2016 VC-12 nonblocking cross-connections.
The card is designed for 2.5-Gbps solutions.
Table 2-15 XC-VXL-10G Card-Level Indicators
Card-Level LEDs Definition
Red FAIL LED Indicates that the card’s processor is not ready. The FAIL LED is on during
reset and flashes during the boot process. Replace the card if the red FAIL
LED persists.
ACT/STBY LED
Green (Active)
Amber (Standby)
Indicates whether the XC-VXL-10G card is active and carrying traffic
(green) or in standby mode to the active XC-VXL-10G card (amber).
