2-5
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 2 Common Control Cards
2.2 TCC2 Card
Table 2-6 lists the cross-connect card compatibility for the FC_MR-4 card. “Yes” means that the storage
area network (SAN) card is compatible with the listed cross-connect card. Table cells with dashes mean
cards are not compatible with the listed cross-connect cards. For software compatibility, see the
“6.1.3 FC_MR-4 Compatibility” section on page 6-3.
2.2 TCC2 Card
Note For TCC2 card specifications, see the “A.4.1 TCC2 Card Specifications” section on page A-10.
The TCC2 card, which requires Software Release 4.0 or later, performs system initialization,
provisioning, alarm reporting, maintenance, diagnostics, IP address detection/resolution, SDH section
overhead (SOH) data communications channel/generic communication channel (DCC/GCC)
termination, and system fault detection for the ONS 15454 SDH. The TCC2 card also ensures that the
system maintains Stratum 3 timing requirements. It monitors the supply voltage of the system.
Note The LAN interfaces of the TCC2 card meet the standard Ethernet specifications by supporting a cable
length of 100 m (328 ft.) at temperatures from 0 to 65 degrees Celsius (32 to 149 degrees Fahrenheit).
The interfaces can operate with a cable length of 10 m (32.8 ft) maximum at temperatures from
–40 to 0 degrees Celsius (–40 to 32 degrees Fahrenheit).
Figure 2-1 shows the TCC2 card faceplate and block diagram.
ML1000-2
Yes Yes Yes Yes
ML100X-8
Yes Yes Yes Yes
CE-100T-8
—YesYesYes
CE-1000-4
Yes Yes Yes Yes
Table 2-6 Ethernet Card Cross-Connect Compatibility (continued)
Ethernet Cards XC10G Card XC-VXL-2.5G Card XC-VXL-10G Card XC-VXC-10G Card
Table 2-7 SAN Card Cross-Connect Compatibility
SAN
Cards XC10G Card
XC-VXL_2.5G
Card
XC-VXL_10G
Card
XC-VXC-10G
Card
FC_MR-4
— Yes Yes Yes
