2-4
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 2 Common Control Cards
2.1.3 Cross-Connect Card Compatibility
Table 2-5 lists the cross-connect card compatibility for each optical card. “Yes” means that the optical
card is compatible with the listed cross-connect card. Table cells with dashes mean cards are not
compatible with the listed cross-connect cards. For optical card software compatibility, see Table 4-2 on
page 4-4.
Table 2-6 lists the cross-connect card compatibility for each Ethernet card.
DS3i-N-12
Yes Yes Yes Yes
STM1E-12
—YesYesYes
Table 2-4 Electrical Card Cross-Connect Compatibility (continued)
Electrical Card XC10G Card XC-VXL-2.5G Card XC-VXL-10G Card XC-VXC-10G Card
Table 2-5 Optical Card Cross-Connect Compatibility
Optical Card XC10G Card XC-VXL-2.5G Card XC-VXL-10G Card XC-VXC-10G Card
OC3 IR 4/STM1 SH 1310
Yes Yes Yes Yes
OC3 IR /STM1SH 1310-8
Yes Yes Yes Yes
OC12 IR/STM4 SH 1310
Yes Yes Yes Yes
OC12 LR/STM4 LH 1310
Yes Yes Yes Yes
OC12 LR/STM4 LH 1550
Yes Yes Yes Yes
OC12 IR/STM4 SH 1310-4
Yes Yes Yes Yes
OC48 IR/STM16 SH AS 1310
Yes Yes Yes Yes
OC48 LR/STM16 LH AS 1550
Yes Yes Yes Yes
OC48 ELR/STM16 EH 100 GHz
Yes Yes Yes Yes
OC192 SR/STM64 IO 1310
Yes — Yes Yes
OC192 IR/STM64 SH 1550
Yes — Yes Yes
OC192 LR/STM64 LH 1550
Yes — Yes Yes
OC192 LR/STM64 LH ITU
15xx.xx
Yes — Yes Yes
OC192SR1/STM64IO
Short Reach and
OC192/STM64 Any Reach
1
1. Designated as STM64-XFP in CTC
—— Yes Yes
15454_MRC-12
— Yes Yes Yes
Table 2-6 Ethernet Card Cross-Connect Compatibility
Ethernet Cards XC10G Card XC-VXL-2.5G Card XC-VXL-10G Card XC-VXC-10G Card
E100T-G
Yes Yes Yes Yes
E1000-2-G
Yes Yes Yes Yes
G1000-4
Yes Yes Yes Yes
G1K-4
Yes Yes Yes Yes
ML100T-12
Yes Yes Yes Yes
