Chapter 2 Common Control Cards
2.1.3 Cross-Connect Card Compatibility
2.1.3 Cross-Connect Card Compatibility
The following tables list the compatible cross-connect cards for each Cisco ONS 15454 SDH
common-control card. The tables are organized according to type of common-control card. In the tables
below, “Yes” means the card is compatible with the listed cross-connect card. Table cells with dashes
mean cards are not compatible with the listed cross-connect card.
Table 2-3 lists the cross-connect card compatibility for each common-control card.
Table 2-4 lists the cross-connect card compatibility for each electrical card. “Yes” means that the
electrical card is compatible with the listed cross-connect card. Table cells with dashes mean cards are
not compatible with the listed cross-connect cards. For electrical card software compatibility, see
Table 3-2 on page 3-4.
Table 2-2 Common-Control Card Software Release Compatibility
Card R4.0 R4.1 R4.5 R4.6 R4.7 R5.0 R6.0 R7.0
TCC2
Yes Yes Yes Yes Yes Yes Yes Yes
TCC2P
Yes Yes Yes Yes Yes Yes Yes Yes
XC10G
Yes Yes — Yes — Yes No No
XC-VXL-10G
Yes Yes — Yes — Yes Yes Yes
XC-VXL-2.5G
Yes Yes — Yes — Yes Yes Yes
XC-VXC-10G
—— — — — —YesYes
AIC-I
Yes Yes Yes Yes Yes Yes Yes Yes
Table 2-3 Common-Control Card Cross-Connect Compatibility
Card XC10G Card XC-VXL-2.5G Card XC-VXL-10G Card XC-VXC-10G Card
TCC2
Yes Yes Yes Yes
TCC2P
Yes Yes Yes Yes
XC-VXL-10G
—
1
—
1
Yes —
1
XC-VXL-2.5G
—Yes—
1
—
1
XC10G
Yes — —
1
—
1
XC-VXC-10G
—
1
1. Cross-connect cards are compatible only during an upgrade (downgrades are not supported).
—
1
—
1
Yes
AIC-I
Yes Yes Yes Yes
Table 2-4 Electrical Card Cross-Connect Compatibility
Electrical Card XC10G Card XC-VXL-2.5G Card XC-VXL-10G Card XC-VXC-10G Card
E1-N-14
Yes Yes Yes Yes
E1-42
Yes Yes Yes Yes
E3-12
Yes Yes Yes Yes
