1-23
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 1 Shelf and FMEC Hardware
1.14 Software and Hardware Compatibility
Note For compatibility information of DWDM cards, see the Cisco ONS 15454 DWDM Reference Manual.
If an upgrade is required for compatibility, go to the Cisco Technical Assistance Center (Cisco TAC)
website at http://www.cisco.com/tac.
OC48
ELR/STM16 EH
100 GHz
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC192
SR/STM64 IO
1310
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC192
IR/STM64 SH
1550
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC192 LR/
STM64 LH 1550
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC192 LR/
STM64 LH ITU
15xx.xx
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC192SR1/STM
64IO Short
Reach,
OC192/STM64
Any Reach
1
Not supported Not supported Not supported Fully compatible Fully compatible
MRC-12
2
Not supported Not supported Not supported Fully compatible Fully compatible
MRC-2.5G-12 Not supported Not supported Not supported Not supported Not supported
TXP_MR_10G Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
MXP_2.5G_10G Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
FC_MR-4 Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
1. These cards are designated as STM64-XFP in CTC.
2. Slots 1 to 4 and 14 to 17 give a total bandwidth of up to 2.5Gb/s. Slots 5, 6 , 12 , and 13 give a total bandwidth of up to 10Gb/s
Table 1-8 ONS 15454 SDH Software Release/Hardware Compatibility—XC10G, XC-VXC-10G, and XC-VXL-10G
Configuration (continued)
Hardware
4.0.0x (4.0)
4.1.0x (4.1) 4.6.0x (4.6) 5.0.0x (5.0) 6.0.0x (6.0) 7.0.0x (7.0)
