1-21
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 1 Shelf and FMEC Hardware
1.14 Software and Hardware Compatibility
Table 1-8 shows ONS 15454 SDH software and hardware compatibility for systems configured with the
XC10G, XC-VXC-10G and XC-VXL-10G cards for Releases 4.0, 4.1, 4.6, 5.0, 6.0, and 7.0. Release 4.5
is not supported on the XC10G and XC-VXL-10G cards. XC-VXC-10G is only supported from Release
6.0.
CE-1000-4 Not supported Not supported Not supported Not supported Fully compatible
OC3 IR 4/STM1 SH
1310
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC3IR/STM1SH
1310-8
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC12 IR/STM4 SH
1310
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC12 LR/STM4 LH
1310
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC12 LR/STM4 LH
1550
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC12 IR/STM4 SH
1310-4
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC48 IR/STM16
SH AS 1310
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC48 LR/STM16
LH AS 1550
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC48 ELR/STM16
EH 100 GHz
Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
OC192 SR/STM64
IO 1310
Not supported Not supported Not supported Not supported Not supported
OC192 IR/STM64
SH 1550
Not supported Not supported Not supported Not supported Not supported
OC192 LR/STM64
LH 1550
Not supported Not supported Not supported Not supported Not supported
OC192 LR/STM64
LH ITU 15xx.xx
Not supported Not supported Not supported Not supported Not supported
OC192SR1/STM64I
O Short Reach,
OC192/STM64
Any Reach
1
Not supported Not supported Not supported Not supported Not supported
MRC-12
2
Not supported Not supported Not supported Fully compatible Fully compatible
MRC-2.5G-12 Not supported Not supported Not supported Not supported Not supported
FC_MR-4 Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
1. These cards are designated as STM64-XFP in CTC.
2. Slots 1 to 4 and 14 to 17 give a total bandwidth of up to 622 Mb/s. Slots 5, 6, 12, and 13 give a total bandwidth of up to 2.5 Gb/s
Table 1-7 ONS 15454 SDH Software Release/Hardware Compatibility—XC-VXL-2.5G Configurations (continued)
Hardware
4.0.0x (4.0)
4.1.0x (4.1) 4.6.0x (4.6) 5.0.0x (5.0) 6.0.0x (6.0) 7.0.0x (7.0)
