1-20
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 1 Shelf and FMEC Hardware
1.14 Software and Hardware Compatibility
Caution Removing any active card from the ONS 15454 SDH can result in traffic interruption. Use caution when
replacing cards and verify that only inactive or standby cards are being replaced. If the active card needs
to be replaced, switch it to standby prior to removing the card from the node. For traffic switching
procedures, refer to the Cisco ONS 15454 SDH Procedure Guide.
Note An improper removal (IMPROPRMVL) alarm is raised whenever a card pull (reseat) is performed,
unless the card is deleted in CTC first. The alarm clears after the card replacement is complete.
Note In a subnetwork connection protection (SNCP), pulling the active cross-connect card without a lockout
causes SNCP circuits to switch.
1.14 Software and Hardware Compatibility
Table 1-7 shows ONS 15454 SDH software and hardware compatibility for systems configured with
XC-VXL-2.5G cards for Releases 4.0, 4.1, 4.6, 5.0, 6.0, and 7.0.
Table 1-7 ONS 15454 SDH Software Release/Hardware Compatibility—XC-VXL-2.5G Configurations
Hardware
4.0.0x (4.0)
4.1.0x (4.1) 4.6.0x (4.6) 5.0.0x (5.0) 6.0.0x (6.0) 7.0.0x (7.0)
XC-VXL-2.5G Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
TCC2 Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
TCC2P Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
AIC-I Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
E1N-14 Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
E1-42 Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
E3-12 Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
DS3i-N-12 Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
STM1E-12 Not supported Not supported Fully compatible Fully compatible Fully compatible
E100T-G Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
E1000-2-G Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
G1000-4 Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
G1K-4 Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
ML100T-12 Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
ML-100X-8 Not supported Not supported Not supported Fully compatible Fully compatible
ML1000-2 Fully compatible Fully compatible Fully compatible Fully compatible Fully compatible
ML-MR-10 Not supported Not supported Not supported Not supported Not supported
CE-MR-10 Not supported Not supported Not supported Not supported Not supported
CE-100T-8 Not supported Not supported Fully compatible Fully compatible Fully compatible
