1-19
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 1 Shelf and FMEC Hardware
1.13.2 Card Replacement
1.13.2 Card Replacement
To replace an ONS 15454 SDH card with another card of the same type, you do not need to make any
changes to the database; remove the old card and replace it with a new card. To replace a card with a card
of a different type, physically remove the card and replace it with the new card, then delete the original
card from CTC. For specifics, refer to the Cisco ONS 15454 SDH Procedure Guide.
ML100T-12 12 100 Mbps RJ-45 Faceplate
ML100X-8 8 100 Mbps SC (SFP) Faceplate
ML1000-2 2 1 Gbps LC (SFP) Faceplate
OC3 IR 4/STM1 SH 1310 4 155.52 Mbps (STM-1) SC Faceplate
OC3IR/STM1SH 1310-8 8 155.52 Mbps (STM-1) LC Faceplate
OC12 IR/STM4 SH 1310 1 622.08 Mbps (STM-4) SC Faceplate
OC12 LR/STM4 LH 1310 1 622.08 Mbps (STM-4) SC Faceplate
OC12 LR/STM4 LH 1550 1 622.08 Mbps (STM-4) SC Faceplate
OC12 IR/STM4 SH 1310-4 4 622.08 Mbps (STM-4) SC Faceplate
OC48 IR/STM16 SH AS
1310
1 2488.32 Mbps (STM-16) SC Faceplate
OC48 LR/STM16 LH AS
1550
1 2488.32 Mbps (STM-16) SC Faceplate
OC48 ELR/STM16 EH 100
GHz
1 2488.32 Mbps (STM-16) SC Faceplate
OC192 SR/STM64 IO 1310 1 9.95 Gbps (STM-64) SC Faceplate
OC192 IR/STM64 SH 1550 1 9.95 Gbps (STM-64) SC Faceplate
OC192 LR/STM64 LH 1550 1 9.95 Gbps (STM-64) SC Faceplate
OC192 LR/STM64 LH ITU
15xx.xx
1 9.95 Gbps (STM-64) SC Faceplate
FC_MR-4 4 (only 2
available
in R4.6)
1.0625 Gbps SC Faceplate
15454_MRC-12 12 Up to 2488.32 Mbps
(STM-16), depending on
SFP
LC Faceplate
OC192SR1/STM64IO Short
Reach, OC192/STM64
Any Reach
1
1 9.95 Gbps (STM-64) LC Faceplate
1. These cards are designated as STM64-XFP in CTC.
Table 1-6 Card Ports, Line Rates, and Connectors (continued)
Card Ports Line Rate per Port Connector Types
Connector
Location
