Chapter 1 Shelf and FMEC Hardware
1.13.1 Card Slot Requirements
Table 1-6 lists the number of ports, line rates, connector options, and connector locations for
ONS 15454 SDH optical and electrical cards.
Table 1-5 Slot and Card Symbols
Symbol
Color/Shape Definition
Orange/Circle Slots 1 to 6 and 12 to 17. Only install ONS 15454 SDH cards with a circle symbol
on the faceplate.
Blue/Triangle Slots 5, 6, 12, and 13. Only install ONS 15454 SDH cards with circle or a triangle
symbol on the faceplate.
Purple/Square TCC2/TCC2P slot, Slots 7 and 11. Only install ONS 15454 SDH cards with a
square symbol on the faceplate.
Green/Cross Cross-connect (XC-VXL-2.5G/XC-VXL-10G) slot, that is, Slots 8 and 10. Only
install ONS 15454 SDH cards with a cross symbol on the faceplate.
Red/P Protection slot in 1:N protection schemes.
Red/Diamond AIC-I slot, that is, Slot 9. Only install ONS 15454 SDH cards with a diamond
symbol on the faceplate.
Gold/Star Slots 1 to 4 and 14 to 17. Only install ONS 15454 SDH cards with a star symbol on
the faceplate.
Table 1-6 Card Ports, Line Rates, and Connectors
Card Ports Line Rate per Port Connector Types
Connector
Location
CE-100T-8 8 100 Mbps RJ-45 Faceplate
E1-N-14 14 2.048 Mbps 1.0/2.3 miniature
coax connector
or
DB-37
EFCA
E1-42 14 2.048 Mbps 1.0/2.3 miniature
coax connector
or
Molex 96-pin
LFH connector
EFCA
E3-12 12 34.386 Mbps 1.0/2.3 miniature
coax connector
EFCA
DS3i-N-12 12 44.736 Mbps 1.0/2.3 miniature
coax connector
EFCA
STM1E-12 12 Configurable
155.52 Mbps
or
139.264 Mbps
1.0/2.3 miniature
coax connector
EFCA
E100T-G 12 100 Mbps RJ-45 Faceplate
E1000-2-G 2 1 Gbps SC (GBIC) Faceplate
G1K-4 4 1 Gbps SC (GBIC) Faceplate
