C-55
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.3.1 Time Zones
C.3.1 Time Zones
Table C-17 lists the time zones that apply for node time zone defaults. Time zones in the table are
ordered by their relative relationships to Greenwich Mean Time (GMT), and the default values are
displayed in the correct format for valid default input.
NODE.timing.bits-2.FramingOut FAS+CAS+
CRC
FAS+CRC,
FAS+CAS,
FAS+CAS+CRC,
FAS, Unframed when
FacilityTypeOut E1;
when
FacilityTypeOut
2MHz; FAS+CRC,
FAS+CAS,
FAS+CAS+CRC,
FAS, Unframed,
Unframed - 2Mhz
when
FacilityTypeOut
6MHz
NODE.timing.bits-2.Sa bit 4 4, 5, 6, 7, 8 when
FacilityType E1; N/A
when FacilityType
2MHz; N/A when
FacilityType
64kHz+8kHz
NODE.timing.bits-2.State unlocked unlocked, locked,
disabled
NODE.timing.bits-2.StateOut unlocked unlocked, locked,
disabled
NODE.timing.general.Mode External External, Line, Mixed
NODE.timing.general.ReversionTime 5.0 (minutes) 0.5, 1.0, 1.5 .. 12.0
NODE.timing.general.Revertive FALSE TRUE, FALSE
Table C-16 Node Default Settings (continued)
Default Name Default Value Default Domain
Table C-17 Time Zones
Time Zone (GMT +/– Hours) Default Value
GMT-11:00 (GMT-11:00) Midway Islands, Samoa
GMT-10:00 (GMT-10:00) Hawaiian Islands, Tahiti
GMT-09:00 (GMT-09:00) Anchorage - Alaska
GMT-08:00 (GMT-08:00) Pacific Time (US & Canada), Tijuana
GMT-07:00 (GMT-07:00) Mountain Time (US & Canada)
GMT-07:00 (GMT-07:00) Phoenix - Arizona
