C-52
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.3 Node Default Settings
NODE.security.other.InactiveDuration 45 (days) 1, 2, 3 .. 99 when
DisableInactiveUser
TRUE; 45 when
DisableInactiveUser
FALSE
NODE.security.other.SingleSessionPerUser FALSE TRUE, FALSE
NODE.security.passwordAging.EnforcePasswordAging FALSE TRUE, FALSE
NODE.security.passwordAging.maintenance.AgingPeriod 45 (days) 20 - 90
NODE.security.passwordAging.maintenance.WarningPeriod 5 (days) 2 - 20
NODE.security.passwordAging.provisioning.AgingPeriod 45 (days) 20 - 90
NODE.security.passwordAging.provisioning.WarningPeriod 5 (days) 2 - 20
NODE.security.passwordAging.retrieve.AgingPeriod 45 (days) 20 - 90
NODE.security.passwordAging.retrieve.WarningPeriod 5 (days) 2 - 20
NODE.security.passwordAging.superuser.AgingPeriod 45 (days) 20 - 90
NODE.security.passwordAging.superuser.WarningPeriod 5 (days) 2 - 20
NODE.security.passwordChange.CannotChangeNewPassword FALSE TRUE, FALSE
NODE.security.passwordChange.CannotChangeNewPasswordForNDays 20 (days) 20 - 95
NODE.security.passwordChange.NewPasswordMustDifferFromOldByNCharacters 1
(characters)
1 - 5
NODE.security.passwordChange.PreventReusingLastNPasswords 1 (times) 1 - 10
NODE.security.passwordChange.RequirePasswordChangeOnFirstLoginToNewAcc
ount
FALSE TRUE, FALSE
NODE.security.radiusServer.AccountingPort 1813 (port) 0 - 32767
NODE.security.radiusServer.AuthenticationPort 1812 (port) 0 - 32767
NODE.security.radiusServer.EnableNodeAsFinalAuthenticator TRUE FALSE, TRUE
NODE.security.serialCraftAccess.EnableCraftPort TRUE TRUE, FALSE
NODE.security.shellAccess.AccessState NonSecure Disabled, NonSecure,
Secure
NODE.security.shellAccess.EnableShellPassword FALSE TRUE, FALSE
NODE.security.shellAccess.TelnetPort 23 23 - 9999
NODE.security.snmpAccess.AccessState NonSecure Disabled, NonSecure
NODE.security.tl1Access.AccessState NonSecure Disabled, NonSecure,
Secure
NODE.security.userLockout.FailedLoginsAllowedBeforeLockout 5 (times) 0 - 10
NODE.security.userLockout.LockoutDuration 00:30
(mins:secs)
00:00, 00:05, 00:10 ..
10:00
NODE.security.userLockout.ManualUnlockBySuperuser FALSE TRUE, FALSE
NODE.timing.bits-1.AdminSSMIn STU G811, STU, G812T,
G812L, SETS, DUS
Table C-16 Node Default Settings (continued)
Default Name Default Value Default Domain
