C-48
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.3 Node Default Settings
NODE.general.NtpSntpServer 0.0.0.0 IP Address
NODE.general.ReportLoopbackConditionsOnUnlocked,MaintenancePorts FALSE FALSE, TRUE
NODE.general.TimeZone (GMT-08:00
) Pacific
Time (US &
Canada),
Tijuana
(For applicable time
zones, see Table C-17
on page C-55.)
NODE.general.UseDST TRUE TRUE, FALSE
NODE.network.general.AlarmMissingBackplaneLAN FALSE TRUE, FALSE
NODE.network.general.CtcIpDisplaySuppression FALSE TRUE, FALSE
NODE.network.general.GatewaySettings None LeaveAsIs, None,
ENE, GNE,
ProxyOnlyNode
NODE.network.general.LcdIpSetting Allow
Configuratio
n
Allow Configuration,
Display Only,
Suppress Display
NODE.osi.greTunnel.OspfCost 110 110, 111, 112 .. 65535
NODE.osi.greTunnel.SubnetMask 24 (bits) 8, 9, 10 .. 32
NODE.osi.lapd.Mode AITS AITS, UITS
NODE.osi.lapd.MTU 512 512, 513, 514 .. 1500
NODE.osi.lapd.Role Network Network, User
NODE.osi.lapd.T200 200 (ms) 200, 300, 400 .. 20000
NODE.osi.lapd.T203 10000 (ms) 4000, 4100, 4200 ..
120000
NODE.osi.mainSetup.L1L2LSPBufferSize 512 (bytes) 512 - 1500
NODE.osi.mainSetup.L1LSPBufferSize 512 (bytes) 512 - 1500
NODE.osi.mainSetup.NodeRoutingMode Intermediate
System
Level 1
End System,
Intermediate System
Level 1, Intermediate
System Level 1/Level
2
NODE.osi.subnet.DISPriority 63 1, 2, 3 .. 127
NODE.osi.subnet.ESH 10 (sec) 10, 20, 30 .. 1000
NODE.osi.subnet.GCCISISCost 60 1, 2, 3 .. 63
NODE.osi.subnet.IIH 3 (sec) 1, 2, 3 .. 600
NODE.osi.subnet.ISH 10 (sec) 10, 20, 30 .. 1000
NODE.osi.subnet.LANISISCost 20 1, 2, 3 .. 63
NODE.osi.subnet.LDCCISISCost 40 1, 2, 3 .. 63
NODE.osi.subnet.OSCISISCost 60 1, 2, 3 .. 63
NODE.osi.subnet.SDCCISISCost 60 1, 2, 3 .. 63
Table C-16 Node Default Settings (continued)
Default Name Default Value Default Domain
