Appendix C Network Element Defaults
C.2.3 Defaults by Card
C.2.3.15 FC_MR-4 Card Default Settings
Table C-15 lists the FC_MR-4 (Fibre Channel) card default settings.
MRC-12.pmthresholds.stm4.rs.nearend.15min.UAS 3 (seconds) 0 - 900
MRC-12.pmthresholds.stm4.rs.nearend.1day.BBE 100000 (count) 0 - 53136000
MRC-12.pmthresholds.stm4.rs.nearend.1day.EB 100000 (count) 0 - 53136000
MRC-12.pmthresholds.stm4.rs.nearend.1day.ES 5000 (seconds) 0 - 86400
MRC-12.pmthresholds.stm4.rs.nearend.1day.SEFS 5000 (seconds) 0 - 86400
MRC-12.pmthresholds.stm4.rs.nearend.1day.SES 5000 (seconds) 0 - 86400
MRC-12.pmthresholds.stm4.rs.nearend.1day.UAS 10 (seconds) 0 - 86400
Table C-14 MRC-12 Card Default Settings (continued)
Default Name Default Value Default Domain
Table C-15 FC_MR-4 Card Default Settings
Default Name Default Value Default Domain
FC-MR.config.card.Mode Fibre
Channel/FICO
N Enhanced
Fibre Channel Line Rate, Fibre
Channel/FICON Enhanced when
//.port.MediaType Undefined;
Fibre Channel/FICON Enhanced
when //.port.MediaType FICON
- 1 Gbps ISL, FICON - 2 Gbps
ISL; Fibre Channel Line Rate,
Fibre Channel/FICON Enhanced
when //.port.MediaType Fibre
Channel - 1 Gbps ISL, Fibre
Channel - 2 Gbps ISL
FC-MR.config.port.AINSSoakTime 08:00
(hours:mins)
00:00, 00:15, 00:30 .. 48:00
FC-MR.config.port.distanceExtension.AutoadjustGFPBufferThreshold TRUE TRUE, FALSE
FC-MR.config.port.distanceExtension.AutoDetect TRUE TRUE, FALSE
FC-MR.config.port.distanceExtension.NumCredits 32 2 - 256
FC-MR.config.port.distanceExtension.NumGFPBuffers 16 16, 32, 48 .. 1200
FC-MR.config.port.DistanceExtensionVsLinkRecovery Distance
Extension
Neither Distance Extension nor
Link Recovery, Distance
Extension, LinkRecovery when
MediaType Undefined; Distance
Extension when MediaType
FICON - 1 Gbps ISL, FICON - 2
Gbps ISL; Neither Distance
Extension nor Link Recovery,
Distance Extension,
LinkRecovery when MediaType
Fibre Channel - 1 Gbps ISL,
Fibre Channel - 2 Gbps ISL
