C-43
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
MRC-12.pmthresholds.stm16.rs.nearend.1day.EB 100000 (count) 0 - 206582400
MRC-12.pmthresholds.stm16.rs.nearend.1day.ES 5000 (seconds) 0 - 86400
MRC-12.pmthresholds.stm16.rs.nearend.1day.SEFS 5000 (seconds) 0 - 86400
MRC-12.pmthresholds.stm16.rs.nearend.1day.SES 5000 (seconds) 0 - 86400
MRC-12.pmthresholds.stm16.rs.nearend.1day.UAS 10 (seconds) 0 - 86400
MRC-12.pmthresholds.stm4.ms.farend.15min.BBE 5315 (count) 0 - 552600
MRC-12.pmthresholds.stm4.ms.farend.15min.EB 5315 (count) 0 - 552600
MRC-12.pmthresholds.stm4.ms.farend.15min.ES 87 (seconds) 0 - 900
MRC-12.pmthresholds.stm4.ms.farend.15min.SES 1 (seconds) 0 - 900
MRC-12.pmthresholds.stm4.ms.farend.15min.UAS 3 (seconds) 0 - 900
MRC-12.pmthresholds.stm4.ms.farend.1day.BBE 53150 (count) 0 - 53049600
MRC-12.pmthresholds.stm4.ms.farend.1day.EB 53150 (count) 0 - 53049600
MRC-12.pmthresholds.stm4.ms.farend.1day.ES 864 (seconds) 0 - 86400
MRC-12.pmthresholds.stm4.ms.farend.1day.SES 4 (seconds) 0 - 86400
MRC-12.pmthresholds.stm4.ms.farend.1day.UAS 10 (seconds) 0 - 86400
MRC-12.pmthresholds.stm4.ms.nearend.15min.BBE 5315 (count) 0 - 552600
MRC-12.pmthresholds.stm4.ms.nearend.15min.EB 5315 (count) 0 - 552600
MRC-12.pmthresholds.stm4.ms.nearend.15min.ES 87 (seconds) 0 - 900
MRC-12.pmthresholds.stm4.ms.nearend.15min.PSC 1 (count) 0 - 600
MRC-12.pmthresholds.stm4.ms.nearend.15min.PSC-W 1 (count) 0 - 600
MRC-12.pmthresholds.stm4.ms.nearend.15min.PSD 300 (seconds) 0 - 900
MRC-12.pmthresholds.stm4.ms.nearend.15min.PSD-W 300 (seconds) 0 - 900
MRC-12.pmthresholds.stm4.ms.nearend.15min.SES 1 (seconds) 0 - 900
MRC-12.pmthresholds.stm4.ms.nearend.15min.UAS 3 (seconds) 0 - 900
MRC-12.pmthresholds.stm4.ms.nearend.1day.BBE 53150 (count) 0 - 53049600
MRC-12.pmthresholds.stm4.ms.nearend.1day.EB 53150 (count) 0 - 53049600
MRC-12.pmthresholds.stm4.ms.nearend.1day.ES 864 (seconds) 0 - 86400
MRC-12.pmthresholds.stm4.ms.nearend.1day.PSC 5 (count) 0 - 57600
MRC-12.pmthresholds.stm4.ms.nearend.1day.PSC-W 5 (count) 0 - 57600
MRC-12.pmthresholds.stm4.ms.nearend.1day.PSD 600 (seconds) 0 - 86400
MRC-12.pmthresholds.stm4.ms.nearend.1day.PSD-W 600 (seconds) 0 - 86400
MRC-12.pmthresholds.stm4.ms.nearend.1day.SES 4 (seconds) 0 - 86400
MRC-12.pmthresholds.stm4.ms.nearend.1day.UAS 10 (seconds) 0 - 86400
MRC-12.pmthresholds.stm4.path.farend.15min.BBE 25 (count) 0 - 2159100
MRC-12.pmthresholds.stm4.path.farend.15min.EB 15 (count) 0 - 13305600
MRC-12.pmthresholds.stm4.path.farend.15min.ES 12 (seconds) 0 - 900
Table C-14 MRC-12 Card Default Settings (continued)
Default Name Default Value Default Domain
