C-40
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
MRC-12.pmthresholds.stm1.path.nearend.15min.PJCDIFF 60 (count) 0 - 1200
MRC-12.pmthresholds.stm1.path.nearend.15min.PJCS-PDET 100 (seconds) 0 - 7200000
MRC-12.pmthresholds.stm1.path.nearend.15min.PJCS-PGEN 100 (seconds) 0 - 7200000
MRC-12.pmthresholds.stm1.path.nearend.15min.PPJC-PDET 60 (count) 0 - 7200000
MRC-12.pmthresholds.stm1.path.nearend.15min.PPJC-PGEN 60 (count) 0 - 7200000
MRC-12.pmthresholds.stm1.path.nearend.15min.SES 3 (seconds) 0 - 900
MRC-12.pmthresholds.stm1.path.nearend.15min.UAS 10 (seconds) 0 - 900
MRC-12.pmthresholds.stm1.path.nearend.1day.BBE 250 (count) 0 - 207273600
MRC-12.pmthresholds.stm1.path.nearend.1day.EB 125 (count) 0 - 691200000
MRC-12.pmthresholds.stm1.path.nearend.1day.ES 100 (seconds) 0 - 86400
MRC-12.pmthresholds.stm1.path.nearend.1day.NPJC-PDET 5760 (count) 0 - 691200000
MRC-12.pmthresholds.stm1.path.nearend.1day.NPJC-PGEN 5760 (count) 0 - 691200000
MRC-12.pmthresholds.stm1.path.nearend.1day.PJCDIFF 5760 (count) 0 - 115200
MRC-12.pmthresholds.stm1.path.nearend.1day.PJCS-PDET 9600 (seconds) 0 - 691200000
MRC-12.pmthresholds.stm1.path.nearend.1day.PJCS-PGEN 9600 (seconds) 0 - 691200000
MRC-12.pmthresholds.stm1.path.nearend.1day.PPJC-PDET 5760 (count) 0 - 691200000
MRC-12.pmthresholds.stm1.path.nearend.1day.PPJC-PGEN 5760 (count) 0 - 691200000
MRC-12.pmthresholds.stm1.path.nearend.1day.SES 7 (seconds) 0 - 86400
MRC-12.pmthresholds.stm1.path.nearend.1day.UAS 10 (seconds) 0 - 86400
MRC-12.pmthresholds.stm1.rs.nearend.15min.BBE 10000 (count) 0 - 138600
MRC-12.pmthresholds.stm1.rs.nearend.15min.EB 10000 (count) 0 - 138600
MRC-12.pmthresholds.stm1.rs.nearend.15min.ES 500 (seconds) 0 - 900
MRC-12.pmthresholds.stm1.rs.nearend.15min.SEFS 500 (seconds) 0 - 900
MRC-12.pmthresholds.stm1.rs.nearend.15min.SES 500 (seconds) 0 - 900
MRC-12.pmthresholds.stm1.rs.nearend.15min.UAS 3 (seconds) 0 - 900
MRC-12.pmthresholds.stm1.rs.nearend.1day.BBE 100000 (count) 0 - 13305600
MRC-12.pmthresholds.stm1.rs.nearend.1day.EB 100000 (count) 0 - 13305600
MRC-12.pmthresholds.stm1.rs.nearend.1day.ES 5000 (seconds) 0 - 86400
MRC-12.pmthresholds.stm1.rs.nearend.1day.SEFS 5000 (seconds) 0 - 86400
MRC-12.pmthresholds.stm1.rs.nearend.1day.SES 5000 (seconds) 0 - 86400
MRC-12.pmthresholds.stm1.rs.nearend.1day.UAS 10 (seconds) 0 - 86400
MRC-12.pmthresholds.stm16.ms.farend.15min.BBE 21260 (count) 0 - 2212200
MRC-12.pmthresholds.stm16.ms.farend.15min.EB 21260 (count) 0 - 2212200
MRC-12.pmthresholds.stm16.ms.farend.15min.ES 87 (seconds) 0 - 900
MRC-12.pmthresholds.stm16.ms.farend.15min.SES 1 (seconds) 0 - 900
MRC-12.pmthresholds.stm16.ms.farend.15min.UAS 3 (seconds) 0 - 900
Table C-14 MRC-12 Card Default Settings (continued)
Default Name Default Value Default Domain
