C-37
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
MRC-12.physicalthresholds.stm1.alarm.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0,
OPT-LOW + 2.0 .. 255.0
MRC-12.physicalthresholds.stm1.alarm.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
MRC-12.physicalthresholds.stm1.warning.15min.LBC-HIGH 200 (%) LBC-LOW, LBC-LOW + 1.0,
LBC-LOW + 2.0 .. 255.0
MRC-12.physicalthresholds.stm1.warning.15min.LBC-LOW 20 (%) 0.0, 1.0, 2.0 .. LBC-HIGH
MRC-12.physicalthresholds.stm1.warning.15min.OPR-HIGH 200 (%) OPR-LOW, OPR-LOW + 1.0,
OPR-LOW + 2.0 .. 255.0
MRC-12.physicalthresholds.stm1.warning.15min.OPR-LOW 50 (%) -1.0, 0.0, 1.0 .. OPR-HIGH
MRC-12.physicalthresholds.stm1.warning.15min.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0,
OPT-LOW + 2.0 .. 255.0
MRC-12.physicalthresholds.stm1.warning.15min.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
MRC-12.physicalthresholds.stm1.warning.1day.LBC-HIGH 200 (%) LBC-LOW, LBC-LOW + 1.0,
LBC-LOW + 2.0 .. 255.0
MRC-12.physicalthresholds.stm1.warning.1day.LBC-LOW 20 (%) 0.0, 1.0, 2.0 .. LBC-HIGH
MRC-12.physicalthresholds.stm1.warning.1day.OPR-HIGH 200 (%) OPR-LOW, OPR-LOW + 1.0,
OPR-LOW + 2.0 .. 255.0
MRC-12.physicalthresholds.stm1.warning.1day.OPR-LOW 50 (%) -1.0, 0.0, 1.0 .. OPR-HIGH
MRC-12.physicalthresholds.stm1.warning.1day.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0,
OPT-LOW + 2.0 .. 255.0
MRC-12.physicalthresholds.stm1.warning.1day.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
MRC-12.physicalthresholds.stm16.alarm.LBC-HIGH 200 (%) LBC-LOW, LBC-LOW + 1.0,
LBC-LOW + 2.0 .. 255.0
MRC-12.physicalthresholds.stm16.alarm.LBC-LOW 20 (%) 0.0, 1.0, 2.0 .. LBC-HIGH
MRC-12.physicalthresholds.stm16.alarm.OPR-HIGH 200 (%) OPR-LOW, OPR-LOW + 1.0,
OPR-LOW + 2.0 .. 255.0
MRC-12.physicalthresholds.stm16.alarm.OPR-LOW 50 (%) -1.0, 0.0, 1.0 .. OPR-HIGH
MRC-12.physicalthresholds.stm16.alarm.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0,
OPT-LOW + 2.0 .. 255.0
MRC-12.physicalthresholds.stm16.alarm.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
MRC-12.physicalthresholds.stm16.warning.15min.LBC-HIGH 200 (%) LBC-LOW, LBC-LOW + 1.0,
LBC-LOW + 2.0 .. 255.0
MRC-12.physicalthresholds.stm16.warning.15min.LBC-LOW 20 (%) 0.0, 1.0, 2.0 .. LBC-HIGH
MRC-12.physicalthresholds.stm16.warning.15min.OPR-HIGH 200 (%) OPR-LOW, OPR-LOW + 1.0,
OPR-LOW + 2.0 .. 255.0
MRC-12.physicalthresholds.stm16.warning.15min.OPR-LOW 50 (%) -1.0, 0.0, 1.0 .. OPR-HIGH
MRC-12.physicalthresholds.stm16.warning.15min.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0,
OPT-LOW + 2.0 .. 255.0
MRC-12.physicalthresholds.stm16.warning.15min.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
Table C-14 MRC-12 Card Default Settings (continued)
Default Name Default Value Default Domain
