Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
C.2.3.14 MRC-12 Card Default Settings
Table C-14 lists the MRC-12 card default settings.
STM64-XFP.pmthresholds.rs.nearend.1day.EB 100000 (count) 0 - 764899200
STM64-XFP.pmthresholds.rs.nearend.1day.ES 5000 (seconds) 0 - 86400
STM64-XFP.pmthresholds.rs.nearend.1day.SEFS 5000 (seconds) 0 - 86400
STM64-XFP.pmthresholds.rs.nearend.1day.SES 5000 (seconds) 0 - 86400
STM64-XFP.pmthresholds.rs.nearend.1day.UAS 10 (seconds) 0 - 86400
Table C-13 STM64-XFP Default Settings (continued)
Default Name Default Value Default Domain
Table C-14 MRC-12 Card Default Settings
Default Name Default Value Default Domain
MRC-12.config.stm1.line.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
MRC-12.config.stm1.line.AlsMode Disabled Disabled, Auto Restart, Manual
Restart, Manual Restart for Test
MRC-12.config.stm1.line.AlsRecoveryPulseDuration 2.0 (seconds) 2.0, 2.1, 2.2 .. 100.0 when AlsMode
Disabled, Auto Restart, Manual
Restart; 80.0, 80.1, 80.2 .. 100.0
when AlsMode Manual Restart for
Test
MRC-12.config.stm1.line.AlsRecoveryPulseInterval 100 (seconds) 60 - 300
MRC-12.config.stm1.line.PJVC4Mon# 0 (VC4 #) 0 - 1
MRC-12.config.stm1.line.SDBER 1.00E-07 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
MRC-12.config.stm1.line.Send<FF>DoNotUse FALSE FALSE when SendDoNotUse
TRUE; FALSE, TRUE when
SendDoNotUse FALSE
MRC-12.config.stm1.line.SendDoNotUse FALSE FALSE, TRUE
MRC-12.config.stm1.line.SFBER 1.00E-04 1E-3, 1E-4, 1E-5
MRC-12.config.stm1.line.State unlocked,
automaticInService
unlocked, locked, disabled, locked,
maintenance, unlocked,
automaticInService
MRC-12.config.stm1.line.SyncMsgIn TRUE FALSE, TRUE
MRC-12.config.stm1.vc4.IPPMEnabled FALSE TRUE, FALSE
MRC-12.config.stm16.line.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
MRC-12.config.stm16.line.AlsMode Disabled Disabled, Auto Restart, Manual
Restart, Manual Restart for Test
MRC-12.config.stm16.line.AlsRecoveryPulseDuration 2.0 (seconds) 2.0, 2.1, 2.2 .. 100.0 when AlsMode
Disabled, Auto Restart, Manual
Restart; 80.0, 80.1, 80.2 .. 100.0
when AlsMode Manual Restart for
Test
