C-33
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
STM64-XFP.pmthresholds.ms.farend.1day.BBE 850400 (count) 0 - 849657600
STM64-XFP.pmthresholds.ms.farend.1day.EB 850400 (count) 0 - 849657600
STM64-XFP.pmthresholds.ms.farend.1day.ES 864 (seconds) 0 - 86400
STM64-XFP.pmthresholds.ms.farend.1day.SES 4 (seconds) 0 - 86400
STM64-XFP.pmthresholds.ms.farend.1day.UAS 10 (seconds) 0 - 86400
STM64-XFP.pmthresholds.ms.nearend.15min.BBE 85040 (count) 0 - 8850600
STM64-XFP.pmthresholds.ms.nearend.15min.EB 85040 (count) 0 - 8850600
STM64-XFP.pmthresholds.ms.nearend.15min.ES 87 (seconds) 0 - 900
STM64-XFP.pmthresholds.ms.nearend.15min.PSC 1 (count) 0 - 600
STM64-XFP.pmthresholds.ms.nearend.15min.PSC-R 1 (count) 0 - 600
STM64-XFP.pmthresholds.ms.nearend.15min.PSC-S 1 (count) 0 - 600
STM64-XFP.pmthresholds.ms.nearend.15min.PSC-W 1 (count) 0 - 600
STM64-XFP.pmthresholds.ms.nearend.15min.PSD 300 (seconds) 0 - 900
STM64-XFP.pmthresholds.ms.nearend.15min.PSD-R 300 (seconds) 0 - 900
STM64-XFP.pmthresholds.ms.nearend.15min.PSD-S 300 (seconds) 0 - 900
STM64-XFP.pmthresholds.ms.nearend.15min.PSD-W 300 (seconds) 0 - 900
STM64-XFP.pmthresholds.ms.nearend.15min.SES 1 (seconds) 0 - 900
STM64-XFP.pmthresholds.ms.nearend.15min.UAS 3 (seconds) 0 - 900
STM64-XFP.pmthresholds.ms.nearend.1day.BBE 850400 (count) 0 - 849657600
STM64-XFP.pmthresholds.ms.nearend.1day.EB 850400 (count) 0 - 849657600
STM64-XFP.pmthresholds.ms.nearend.1day.ES 864 (seconds) 0 - 86400
STM64-XFP.pmthresholds.ms.nearend.1day.PSC 5 (count) 0 - 57600
STM64-XFP.pmthresholds.ms.nearend.1day.PSC-R 5 (count) 0 - 57600
STM64-XFP.pmthresholds.ms.nearend.1day.PSC-S 5 (count) 0 - 57600
STM64-XFP.pmthresholds.ms.nearend.1day.PSC-W 5 (count) 0 - 57600
STM64-XFP.pmthresholds.ms.nearend.1day.PSD 600 (seconds) 0 - 86400
STM64-XFP.pmthresholds.ms.nearend.1day.PSD-R 600 (seconds) 0 - 86400
STM64-XFP.pmthresholds.ms.nearend.1day.PSD-S 600 (seconds) 0 - 86400
STM64-XFP.pmthresholds.ms.nearend.1day.PSD-W 600 (seconds) 0 - 86400
STM64-XFP.pmthresholds.ms.nearend.1day.SES 4 (seconds) 0 - 86400
STM64-XFP.pmthresholds.ms.nearend.1day.UAS 10 (seconds) 0 - 86400
STM64-XFP.pmthresholds.path.farend.15min.BBE 25 (count) 0 - 2159100
STM64-XFP.pmthresholds.path.farend.15min.EB 15 (count) 0 - 7200000
STM64-XFP.pmthresholds.path.farend.15min.ES 12 (seconds) 0 - 900
STM64-XFP.pmthresholds.path.farend.15min.SES 3 (seconds) 0 - 900
STM64-XFP.pmthresholds.path.farend.15min.UAS 10 (seconds) 0 - 900
Table C-13 STM64-XFP Default Settings (continued)
Default Name Default Value Default Domain
