C-32
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
STM64-XFP.config.line.SendDoNotUse FALSE FALSE, TRUE
STM64-XFP.config.line.SFBER 1.00E-04 1E-3, 1E-4, 1E-5
STM64-XFP.config.line.State unlocked,
automaticInService
unlocked, locked, disabled, locked,
maintenance, unlocked,
automaticInService
STM64-XFP.config.line.SyncMsgIn TRUE FALSE, TRUE
STM64-XFP.config.vc4.IPPMEnabled FALSE TRUE, FALSE
STM64-XFP.physicalthresholds.alarm.LBC-HIGH 200 (%) LBC-LOW, LBC-LOW + 1.0,
LBC-LOW + 2.0 .. 255.0
STM64-XFP.physicalthresholds.alarm.LBC-LOW 20 (%) 0.0, 1.0, 2.0 .. LBC-HIGH
STM64-XFP.physicalthresholds.alarm.OPR-HIGH 200 (%) OPR-LOW, OPR-LOW + 1.0,
OPR-LOW + 2.0 .. 255.0
STM64-XFP.physicalthresholds.alarm.OPR-LOW 50 (%) -1.0, 0.0, 1.0 .. OPR-HIGH
STM64-XFP.physicalthresholds.alarm.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0,
OPT-LOW + 2.0 .. 255.0
STM64-XFP.physicalthresholds.alarm.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
STM64-XFP.physicalthresholds.warning.15min.LBC-HIGH 200 (%) LBC-LOW, LBC-LOW + 1.0,
LBC-LOW + 2.0 .. 255.0
STM64-XFP.physicalthresholds.warning.15min.LBC-LOW 20 (%) 0.0, 1.0, 2.0 .. LBC-HIGH
STM64-XFP.physicalthresholds.warning.15min.OPR-HIGH 200 (%) OPR-LOW, OPR-LOW + 1.0,
OPR-LOW + 2.0 .. 255.0
STM64-XFP.physicalthresholds.warning.15min.OPR-LOW 50 (%) -1.0, 0.0, 1.0 .. OPR-HIGH
STM64-XFP.physicalthresholds.warning.15min.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0,
OPT-LOW + 2.0 .. 255.0
STM64-XFP.physicalthresholds.warning.15min.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
STM64-XFP.physicalthresholds.warning.1day.LBC-HIGH 200 (%) LBC-LOW, LBC-LOW + 1.0,
LBC-LOW + 2.0 .. 255.0
STM64-XFP.physicalthresholds.warning.1day.LBC-LOW 20 (%) 0.0, 1.0, 2.0 .. LBC-HIGH
STM64-XFP.physicalthresholds.warning.1day.OPR-HIGH 200 (%) OPR-LOW, OPR-LOW + 1.0,
OPR-LOW + 2.0 .. 255.0
STM64-XFP.physicalthresholds.warning.1day.OPR-LOW 50 (%) -1.0, 0.0, 1.0 .. OPR-HIGH
STM64-XFP.physicalthresholds.warning.1day.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0,
OPT-LOW + 2.0 .. 255.0
STM64-XFP.physicalthresholds.warning.1day.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
STM64-XFP.pmthresholds.ms.farend.15min.BBE 85040 (count) 0 - 8850600
STM64-XFP.pmthresholds.ms.farend.15min.EB 85040 (count) 0 - 8850600
STM64-XFP.pmthresholds.ms.farend.15min.ES 87 (seconds) 0 - 900
STM64-XFP.pmthresholds.ms.farend.15min.SES 1 (seconds) 0 - 900
STM64-XFP.pmthresholds.ms.farend.15min.UAS 3 (seconds) 0 - 900
Table C-13 STM64-XFP Default Settings (continued)
Default Name Default Value Default Domain
