C-31
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
C.2.3.13 STM64-XFP Default Settings
Table C-13 lists the STM64-XFP default settings.
STM64.pmthresholds.path.nearend.1day.PJCDIFF 5760 (count) 0 - 1382400000
STM64.pmthresholds.path.nearend.1day.PJCS-PDET 9600 (seconds) 0 - 86400
STM64.pmthresholds.path.nearend.1day.PJCS-PGEN 9600 (seconds) 0 - 86400
STM64.pmthresholds.path.nearend.1day.PPJC-PDET 5760 (count) 0 - 691200000
STM64.pmthresholds.path.nearend.1day.PPJC-PGEN 5760 (count) 0 - 691200000
STM64.pmthresholds.path.nearend.1day.SES 7 (seconds) 0 - 86400
STM64.pmthresholds.path.nearend.1day.UAS 10 (seconds) 0 - 86400
STM64.pmthresholds.rs.nearend.15min.BBE 10000 (count) 0 - 7967700
STM64.pmthresholds.rs.nearend.15min.EB 10000 (count) 0 - 7967700
STM64.pmthresholds.rs.nearend.15min.ES 500 (seconds) 0 - 900
STM64.pmthresholds.rs.nearend.15min.SEFS 500 (seconds) 0 - 900
STM64.pmthresholds.rs.nearend.15min.SES 500 (seconds) 0 - 900
STM64.pmthresholds.rs.nearend.15min.UAS 3 (seconds) 0 - 900
STM64.pmthresholds.rs.nearend.1day.BBE 100000 (count) 0 - 764899200
STM64.pmthresholds.rs.nearend.1day.EB 100000 (count) 0 - 764899200
STM64.pmthresholds.rs.nearend.1day.ES 5000 (seconds) 0 - 86400
STM64.pmthresholds.rs.nearend.1day.SEFS 5000 (seconds) 0 - 86400
STM64.pmthresholds.rs.nearend.1day.SES 5000 (seconds) 0 - 86400
STM64.pmthresholds.rs.nearend.1day.UAS 10 (seconds) 0 - 86400
Table C-12 STM-64 Card Default Settings (continued)
Default Name Default Value Default Domain
Table C-13 STM64-XFP Default Settings
Default Name Default Value Default Domain
STM64-XFP.config.line.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
STM64-XFP.config.line.AlsMode Disabled Disabled, Auto Restart, Manual
Restart, Manual Restart for Test
STM64-XFP.config.line.AlsRecoveryPulseDuration 2.0 (seconds) 2.0, 2.1, 2.2 .. 100.0 when AlsMode
Disabled, Auto Restart, Manual
Restart; 80.0, 80.1, 80.2 .. 100.0 when
AlsMode Manual Restart for Test
STM64-XFP.config.line.AlsRecoveryPulseInterval 100 (seconds) 60 - 300
STM64-XFP.config.line.PJVC4Mon# 0 (VC4 #) 0 - 64
STM64-XFP.config.line.SDBER 1.00E-07 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
STM64-XFP.config.line.Send<FF>DoNotUse FALSE FALSE when SendDoNotUse TRUE;
FALSE, TRUE when SendDoNotUse
FALSE
