C-29
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
STM64.physicalthresholds.alarm.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0, OPT-LOW +
2.0 .. 255.0
STM64.physicalthresholds.alarm.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
STM64.physicalthresholds.warning.15min.LBC-HIGH 200 (%) LBC-LOW, LBC-LOW + 1.0, LBC-LOW +
2.0 .. 255.0
STM64.physicalthresholds.warning.15min.LBC-LOW 20 (%) 0.0, 1.0, 2.0 .. LBC-HIGH
STM64.physicalthresholds.warning.15min.OPR-HIGH 200 (%) OPR-LOW, OPR-LOW + 1.0, OPR-LOW +
2.0 .. 255.0
STM64.physicalthresholds.warning.15min.OPR-LOW 50 (%) -1.0, 0.0, 1.0 .. OPR-HIGH
STM64.physicalthresholds.warning.15min.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0, OPT-LOW +
2.0 .. 255.0
STM64.physicalthresholds.warning.15min.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
STM64.physicalthresholds.warning.1day.LBC-HIGH 200 (%) LBC-LOW, LBC-LOW + 1.0, LBC-LOW +
2.0 .. 255.0
STM64.physicalthresholds.warning.1day.LBC-LOW 20 (%) 0.0, 1.0, 2.0 .. LBC-HIGH
STM64.physicalthresholds.warning.1day.OPR-HIGH 200 (%) OPR-LOW, OPR-LOW + 1.0, OPR-LOW +
2.0 .. 255.0
STM64.physicalthresholds.warning.1day.OPR-LOW 50 (%) -1.0, 0.0, 1.0 .. OPR-HIGH
STM64.physicalthresholds.warning.1day.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0, OPT-LOW +
2.0 .. 255.0
STM64.physicalthresholds.warning.1day.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
STM64.pmthresholds.ms.farend.15min.BBE 85040 (count) 0 - 8850600
STM64.pmthresholds.ms.farend.15min.EB 85040 (count) 0 - 8850600
STM64.pmthresholds.ms.farend.15min.ES 87 (seconds) 0 - 900
STM64.pmthresholds.ms.farend.15min.SES 1 (seconds) 0 - 900
STM64.pmthresholds.ms.farend.15min.UAS 3 (seconds) 0 - 900
STM64.pmthresholds.ms.farend.1day.BBE 850400 (count) 0 - 849657600
STM64.pmthresholds.ms.farend.1day.EB 850400 (count) 0 - 849657600
STM64.pmthresholds.ms.farend.1day.ES 864 (seconds) 0 - 86400
STM64.pmthresholds.ms.farend.1day.SES 4 (seconds) 0 - 86400
STM64.pmthresholds.ms.farend.1day.UAS 10 (seconds) 0 - 86400
STM64.pmthresholds.ms.nearend.15min.BBE 85040 (count) 0 - 8850600
STM64.pmthresholds.ms.nearend.15min.EB 85040 (count) 0 - 8850600
STM64.pmthresholds.ms.nearend.15min.ES 87 (seconds) 0 - 900
STM64.pmthresholds.ms.nearend.15min.PSC 1 (count) 0 - 600
STM64.pmthresholds.ms.nearend.15min.PSC-R 1 (count) 0 - 600
STM64.pmthresholds.ms.nearend.15min.PSC-S 1 (count) 0 - 600
STM64.pmthresholds.ms.nearend.15min.PSC-W 1 (count) 0 - 600
Table C-12 STM-64 Card Default Settings (continued)
Default Name Default Value Default Domain
