C-27
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
STM16.pmthresholds.ms.nearend.1day.PSD 600 (seconds) 0 - 86400
STM16.pmthresholds.ms.nearend.1day.PSD-R 600 (seconds) 0 - 86400
STM16.pmthresholds.ms.nearend.1day.PSD-S 600 (seconds) 0 - 86400
STM16.pmthresholds.ms.nearend.1day.PSD-W 600 (seconds) 0 - 86400
STM16.pmthresholds.ms.nearend.1day.SES 4 (seconds) 0 - 86400
STM16.pmthresholds.ms.nearend.1day.UAS 10 (seconds) 0 - 86400
STM16.pmthresholds.path.nearend.15min.BBE 25 (count) 0 - 2159100
STM16.pmthresholds.path.nearend.15min.EB 15 (count) 0 - 7200000
STM16.pmthresholds.path.nearend.15min.ES 12 (seconds) 0 - 900
STM16.pmthresholds.path.nearend.15min.NPJC-PDET 60 (count) 0 - 7200000
STM16.pmthresholds.path.nearend.15min.NPJC-PGEN 60 (count) 0 - 7200000
STM16.pmthresholds.path.nearend.15min.PJCDIFF 60 (count) 0 - 14400000
STM16.pmthresholds.path.nearend.15min.PJCS-PDET 100 (seconds) 0 - 900
STM16.pmthresholds.path.nearend.15min.PJCS-PGEN 100 (seconds) 0 - 900
STM16.pmthresholds.path.nearend.15min.PPJC-PDET 60 (count) 0 - 7200000
STM16.pmthresholds.path.nearend.15min.PPJC-PGEN 60 (count) 0 - 7200000
STM16.pmthresholds.path.nearend.15min.SES 3 (seconds) 0 - 900
STM16.pmthresholds.path.nearend.15min.UAS 10 (seconds) 0 - 900
STM16.pmthresholds.path.nearend.1day.BBE 250 (count) 0 - 207273600
STM16.pmthresholds.path.nearend.1day.EB 125 (count) 0 - 691200000
STM16.pmthresholds.path.nearend.1day.ES 100 (seconds) 0 - 86400
STM16.pmthresholds.path.nearend.1day.NPJC-PDET 5760 (count) 0 - 691200000
STM16.pmthresholds.path.nearend.1day.NPJC-PGEN 5760 (count) 0 - 691200000
STM16.pmthresholds.path.nearend.1day.PJCDIFF 5760 (count) 0 - 1382400000
STM16.pmthresholds.path.nearend.1day.PJCS-PDET 9600 (seconds) 0 - 86400
STM16.pmthresholds.path.nearend.1day.PJCS-PGEN 9600 (seconds) 0 - 86400
STM16.pmthresholds.path.nearend.1day.PPJC-PDET 5760 (count) 0 - 691200000
STM16.pmthresholds.path.nearend.1day.PPJC-PGEN 5760 (count) 0 - 691200000
STM16.pmthresholds.path.nearend.1day.SES 7 (seconds) 0 - 86400
STM16.pmthresholds.path.nearend.1day.UAS 10 (seconds) 0 - 86400
STM16.pmthresholds.rs.nearend.15min.BBE 10000 (count) 0 - 2151900
STM16.pmthresholds.rs.nearend.15min.EB 10000 (count) 0 - 2151900
STM16.pmthresholds.rs.nearend.15min.ES 500 (seconds) 0 - 900
STM16.pmthresholds.rs.nearend.15min.SEFS 500 (seconds) 0 - 900
STM16.pmthresholds.rs.nearend.15min.SES 500 (seconds) 0 - 900
STM16.pmthresholds.rs.nearend.15min.UAS 3 (seconds) 0 - 900
Table C-11 STM-16 Card Default Settings (continued)
Default Name Default Value Default Domain
