C-26
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
STM16.config.line.SendDoNotUse FALSE FALSE, TRUE
STM16.config.line.SFBER 1.00E-04 1E-3, 1E-4, 1E-5
STM16.config.line.State unlocked,
automaticInService
unlocked, locked, disabled, locked,
maintenance, unlocked,
automaticInService
STM16.config.line.SyncMsgIn TRUE FALSE, TRUE
STM16.config.vc4.IPPMEnabled FALSE TRUE, FALSE
STM16.pmthresholds.ms.farend.15min.BBE 21260 (count) 0 - 2212200
STM16.pmthresholds.ms.farend.15min.EB 21260 (count) 0 - 2212200
STM16.pmthresholds.ms.farend.15min.ES 87 (seconds) 0 - 900
STM16.pmthresholds.ms.farend.15min.SES 1 (seconds) 0 - 900
STM16.pmthresholds.ms.farend.15min.UAS 3 (seconds) 0 - 900
STM16.pmthresholds.ms.farend.1day.BBE 212600 (count) 0 - 212371200
STM16.pmthresholds.ms.farend.1day.EB 212600 (count) 0 - 212371200
STM16.pmthresholds.ms.farend.1day.ES 864 (seconds) 0 - 86400
STM16.pmthresholds.ms.farend.1day.SES 4 (seconds) 0 - 86400
STM16.pmthresholds.ms.farend.1day.UAS 10 (seconds) 0 - 86400
STM16.pmthresholds.ms.nearend.15min.BBE 21260 (count) 0 - 2212200
STM16.pmthresholds.ms.nearend.15min.EB 21260 (count) 0 - 2212200
STM16.pmthresholds.ms.nearend.15min.ES 87 (seconds) 0 - 900
STM16.pmthresholds.ms.nearend.15min.PSC 1 (count) 0 - 600
STM16.pmthresholds.ms.nearend.15min.PSC-R 1 (count) 0 - 600
STM16.pmthresholds.ms.nearend.15min.PSC-S 1 (count) 0 - 600
STM16.pmthresholds.ms.nearend.15min.PSC-W 1 (count) 0 - 600
STM16.pmthresholds.ms.nearend.15min.PSD 300 (seconds) 0 - 900
STM16.pmthresholds.ms.nearend.15min.PSD-R 300 (seconds) 0 - 900
STM16.pmthresholds.ms.nearend.15min.PSD-S 300 (seconds) 0 - 900
STM16.pmthresholds.ms.nearend.15min.PSD-W 300 (seconds) 0 - 900
STM16.pmthresholds.ms.nearend.15min.SES 1 (seconds) 0 - 900
STM16.pmthresholds.ms.nearend.15min.UAS 3 (seconds) 0 - 900
STM16.pmthresholds.ms.nearend.1day.BBE 212600 (count) 0 - 212371200
STM16.pmthresholds.ms.nearend.1day.EB 212600 (count) 0 - 212371200
STM16.pmthresholds.ms.nearend.1day.ES 864 (seconds) 0 - 86400
STM16.pmthresholds.ms.nearend.1day.PSC 5 (count) 0 - 57600
STM16.pmthresholds.ms.nearend.1day.PSC-R 5 (count) 0 - 57600
STM16.pmthresholds.ms.nearend.1day.PSC-S 5 (count) 0 - 57600
STM16.pmthresholds.ms.nearend.1day.PSC-W 5 (count) 0 - 57600
Table C-11 STM-16 Card Default Settings (continued)
Default Name Default Value Default Domain
