Appendix C Network Element Defaults
C.2.3 Defaults by Card
C.2.3.11 STM-16 Card Default Settings
Table C-11 lists the STM-16 card default settings.
STM4-4.pmthresholds.path.nearend.1day.PJCS-PDET 9600 (seconds) 0 - 86400
STM4-4.pmthresholds.path.nearend.1day.PJCS-PGEN 9600 (seconds) 0 - 86400
STM4-4.pmthresholds.path.nearend.1day.PPJC-PDET 5760 (count) 0 - 691200000
STM4-4.pmthresholds.path.nearend.1day.PPJC-PGEN 5760 (count) 0 - 691200000
STM4-4.pmthresholds.path.nearend.1day.SES 7 (seconds) 0 - 86400
STM4-4.pmthresholds.path.nearend.1day.UAS 10 (seconds) 0 - 86400
STM4-4.pmthresholds.rs.nearend.15min.BBE 10000 (count) 0 - 553500
STM4-4.pmthresholds.rs.nearend.15min.EB 10000 (count) 0 - 553500
STM4-4.pmthresholds.rs.nearend.15min.ES 500 (seconds) 0 - 900
STM4-4.pmthresholds.rs.nearend.15min.SEFS 500 (seconds) 0 - 900
STM4-4.pmthresholds.rs.nearend.15min.SES 500 (seconds) 0 - 900
STM4-4.pmthresholds.rs.nearend.15min.UAS 3 (seconds) 0 - 900
STM4-4.pmthresholds.rs.nearend.1day.BBE 100000 (count) 0 - 53136000
STM4-4.pmthresholds.rs.nearend.1day.EB 100000 (count) 0 - 53136000
STM4-4.pmthresholds.rs.nearend.1day.ES 5000 (seconds) 0 - 86400
STM4-4.pmthresholds.rs.nearend.1day.SEFS 5000 (seconds) 0 - 86400
STM4-4.pmthresholds.rs.nearend.1day.SES 5000 (seconds) 0 - 86400
STM4-4.pmthresholds.rs.nearend.1day.UAS 10 (seconds) 0 - 86400
Table C-10 STM4-4 Card Default Settings (continued)
Default Name Default Value Default Domain
Table C-11 STM-16 Card Default Settings
Default Name Default Value Default Domain
STM16.config.line.AdminSSMIn STU G811, STU, G812T, G812L, SETS, DUS
STM16.config.line.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
STM16.config.line.AlsMode Disabled Disabled, Auto Restart, Manual Restart,
Manual Restart for Test
STM16.config.line.AlsRecoveryPulseDuration 2.0 (seconds) 2.0, 2.1, 2.2 .. 100.0 when AlsMode
Disabled, Auto Restart, Manual Restart;
80.0, 80.1, 80.2 .. 100.0 when AlsMode
Manual Restart for Test
STM16.config.line.AlsRecoveryPulseInterval 100 (seconds) 60 - 300
STM16.config.line.PJVC4Mon# 0 (VC4 #) 0 - 16
STM16.config.line.SDBER 1.00E-07 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
STM16.config.line.Send<FF>DoNotUse FALSE FALSE when SendDoNotUse TRUE;
FALSE, TRUE when SendDoNotUse
FALSE
