Appendix C Network Element Defaults
C.2.3 Defaults by Card
C.2.3.10 STM4-4 Card Default Settings
Table C-10 lists the STM4-4 card default settings.
STM4.pmthresholds.rs.nearend.15min.UAS 3 (seconds) 0 - 900
STM4.pmthresholds.rs.nearend.1day.BBE 100000 (count) 0 - 53136000
STM4.pmthresholds.rs.nearend.1day.EB 100000 (count) 0 - 53136000
STM4.pmthresholds.rs.nearend.1day.ES 5000 (seconds) 0 - 86400
STM4.pmthresholds.rs.nearend.1day.SEFS 5000 (seconds) 0 - 86400
STM4.pmthresholds.rs.nearend.1day.SES 5000 (seconds) 0 - 86400
STM4.pmthresholds.rs.nearend.1day.UAS 10 (seconds) 0 - 86400
Table C-9 STM-4 Card Default Settings (continued)
Default Name Default Value Default Domain
Table C-10 STM4-4 Card Default Settings
Default Name Default Value Default Domain
STM4-4.config.line.AdminSSMIn STU G811, STU, G812T, G812L, SETS, DUS
STM4-4.config.line.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
STM4-4.config.line.PJVC4Mon# 0 (VC4 #) 0 - 4
STM4-4.config.line.SDBER 1.00E-07 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
STM4-4.config.line.Send<FF>DoNotUse FALSE FALSE when SendDoNotUse TRUE;
FALSE, TRUE when SendDoNotUse
FALSE
STM4-4.config.line.SendDoNotUse FALSE FALSE, TRUE
STM4-4.config.line.SFBER 1.00E-04 1E-3, 1E-4, 1E-5
STM4-4.config.line.State unlocked,
automaticInService
unlocked, locked, disabled, locked,
maintenance, unlocked,
automaticInService
STM4-4.config.line.SyncMsgIn TRUE FALSE, TRUE
STM4-4.config.vc4.IPPMEnabled FALSE TRUE, FALSE
STM4-4.pmthresholds.ms.farend.15min.BBE 5315 (count) 0 - 552600
STM4-4.pmthresholds.ms.farend.15min.EB 5315 (count) 0 - 552600
STM4-4.pmthresholds.ms.farend.15min.ES 87 (seconds) 0 - 900
STM4-4.pmthresholds.ms.farend.15min.SES 1 (seconds) 0 - 900
STM4-4.pmthresholds.ms.farend.15min.UAS 3 (seconds) 0 - 900
STM4-4.pmthresholds.ms.farend.1day.BBE 53150 (count) 0 - 53049600
STM4-4.pmthresholds.ms.farend.1day.EB 53150 (count) 0 - 53049600
STM4-4.pmthresholds.ms.farend.1day.ES 864 (seconds) 0 - 86400
STM4-4.pmthresholds.ms.farend.1day.SES 4 (seconds) 0 - 86400
STM4-4.pmthresholds.ms.farend.1day.UAS 10 (seconds) 0 - 86400
