C-19
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
STM1-8.pmthresholds.ms.farend.15min.ES 87 (seconds) 0 - 900
STM1-8.pmthresholds.ms.farend.15min.SES 1 (seconds) 0 - 900
STM1-8.pmthresholds.ms.farend.15min.UAS 3 (seconds) 0 - 900
STM1-8.pmthresholds.ms.farend.1day.BBE 13120 (count) 0 - 13219200
STM1-8.pmthresholds.ms.farend.1day.EB 13120 (count) 0 - 13219200
STM1-8.pmthresholds.ms.farend.1day.ES 864 (seconds) 0 - 86400
STM1-8.pmthresholds.ms.farend.1day.SES 4 (seconds) 0 - 86400
STM1-8.pmthresholds.ms.farend.1day.UAS 10 (seconds) 0 - 86400
STM1-8.pmthresholds.ms.nearend.15min.BBE 1312 (count) 0 - 137700
STM1-8.pmthresholds.ms.nearend.15min.EB 1312 (count) 0 - 137700
STM1-8.pmthresholds.ms.nearend.15min.ES 87 (seconds) 0 - 900
STM1-8.pmthresholds.ms.nearend.15min.PSC 1 (count) 0 - 600
STM1-8.pmthresholds.ms.nearend.15min.PSD 300 (seconds) 0 - 900
STM1-8.pmthresholds.ms.nearend.15min.SES 1 (seconds) 0 - 900
STM1-8.pmthresholds.ms.nearend.15min.UAS 3 (seconds) 0 - 900
STM1-8.pmthresholds.ms.nearend.1day.BBE 13120 (count) 0 - 13219200
STM1-8.pmthresholds.ms.nearend.1day.EB 13120 (count) 0 - 13219200
STM1-8.pmthresholds.ms.nearend.1day.ES 864 (seconds) 0 - 86400
STM1-8.pmthresholds.ms.nearend.1day.PSC 5 (count) 0 - 57600
STM1-8.pmthresholds.ms.nearend.1day.PSD 600 (seconds) 0 - 86400
STM1-8.pmthresholds.ms.nearend.1day.SES 4 (seconds) 0 - 86400
STM1-8.pmthresholds.ms.nearend.1day.UAS 10 (seconds) 0 - 86400
STM1-8.pmthresholds.path.farend.15min.BBE 25 (count) 0 - 2159100
STM1-8.pmthresholds.path.farend.15min.EB 15 (count) 0 - 13305600
STM1-8.pmthresholds.path.farend.15min.ES 12 (seconds) 0 - 900
STM1-8.pmthresholds.path.farend.15min.SES 3 (seconds) 0 - 900
STM1-8.pmthresholds.path.farend.15min.UAS 10 (seconds) 0 - 900
STM1-8.pmthresholds.path.farend.1day.BBE 250 (count) 0 - 207273600
STM1-8.pmthresholds.path.farend.1day.EB 125 (count) 0 - 691200000
STM1-8.pmthresholds.path.farend.1day.ES 100 (seconds) 0 - 86400
STM1-8.pmthresholds.path.farend.1day.SES 7 (seconds) 0 - 86400
STM1-8.pmthresholds.path.farend.1day.UAS 10 (seconds) 0 - 86400
STM1-8.pmthresholds.path.nearend.15min.BBE 25 (count) 0 - 2159100
STM1-8.pmthresholds.path.nearend.15min.EB 15 (count) 0 - 7200000
STM1-8.pmthresholds.path.nearend.15min.ES 12 (seconds) 0 - 900
STM1-8.pmthresholds.path.nearend.15min.NPJC-PDET 60 (count) 0 - 7200000
Table C-8 STM1-8 Card Default Settings (continued)
Default Name Default Value Default Domain
