C-18
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
STM1-8.config.line.SDBER 1.00E-07 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
STM1-8.config.line.Send<FF>DoNotUse FALSE FALSE when SendDoNotUse TRUE;
FALSE, TRUE when SendDoNotUse
FALSE
STM1-8.config.line.SendDoNotUse FALSE FALSE, TRUE
STM1-8.config.line.SFBER 1.00E-04 1E-3, 1E-4, 1E-5
STM1-8.config.line.State unlocked,
automaticInService
unlocked, locked, disabled, locked,
maintenance, unlocked,
automaticInService
STM1-8.config.line.SyncMsgIn TRUE FALSE, TRUE
STM1-8.config.vc4.IPPMEnabled FALSE TRUE, FALSE
STM1-8.physicalthresholds.alarm.LBC-HIGH 200 (%) LBC-LOW, LBC-LOW + 1.0, LBC-LOW
+ 2.0 .. 255.0
STM1-8.physicalthresholds.alarm.LBC-LOW 20 (%) 0.0, 1.0, 2.0 .. LBC-HIGH
STM1-8.physicalthresholds.alarm.OPR-HIGH 200 (%) OPR-LOW, OPR-LOW + 1.0, OPR-LOW
+ 2.0 .. 255.0
STM1-8.physicalthresholds.alarm.OPR-LOW 50 (%) -1.0, 0.0, 1.0 .. OPR-HIGH
STM1-8.physicalthresholds.alarm.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0, OPT-LOW +
2.0 .. 255.0
STM1-8.physicalthresholds.alarm.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
STM1-8.physicalthresholds.warning.15min.LBC-HIGH 200 (%) LBC-LOW, LBC-LOW + 1.0, LBC-LOW
+ 2.0 .. 255.0
STM1-8.physicalthresholds.warning.15min.LBC-LOW 20 (%) 0.0, 1.0, 2.0 .. LBC-HIGH
STM1-8.physicalthresholds.warning.15min.OPR-HIGH 200 (%) OPR-LOW, OPR-LOW + 1.0, OPR-LOW
+ 2.0 .. 255.0
STM1-8.physicalthresholds.warning.15min.OPR-LOW 50 (%) -1.0, 0.0, 1.0 .. OPR-HIGH
STM1-8.physicalthresholds.warning.15min.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0, OPT-LOW +
2.0 .. 255.0
STM1-8.physicalthresholds.warning.15min.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
STM1-8.physicalthresholds.warning.1day.LBC-HIGH 200 (%) LBC-LOW, LBC-LOW + 1.0, LBC-LOW
+ 2.0 .. 255.0
STM1-8.physicalthresholds.warning.1day.LBC-LOW 20 (%) 0.0, 1.0, 2.0 .. LBC-HIGH
STM1-8.physicalthresholds.warning.1day.OPR-HIGH 200 (%) OPR-LOW, OPR-LOW + 1.0, OPR-LOW
+ 2.0 .. 255.0
STM1-8.physicalthresholds.warning.1day.OPR-LOW 50 (%) -1.0, 0.0, 1.0 .. OPR-HIGH
STM1-8.physicalthresholds.warning.1day.OPT-HIGH 120 (%) OPT-LOW, OPT-LOW + 1.0, OPT-LOW +
2.0 .. 255.0
STM1-8.physicalthresholds.warning.1day.OPT-LOW 80 (%) 0.0, 1.0, 2.0 .. OPT-HIGH
STM1-8.pmthresholds.ms.farend.15min.BBE 1312 (count) 0 - 137700
STM1-8.pmthresholds.ms.farend.15min.EB 1312 (count) 0 - 137700
Table C-8 STM1-8 Card Default Settings (continued)
Default Name Default Value Default Domain
