C-17
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
C.2.3.8 STM1-8 Card Default Settings
Table C-8 lists the STM1-8 card default settings.
STM1.pmthresholds.path.nearend.1day.NPJC-PDET 5760 (count) 0 - 691200000
STM1.pmthresholds.path.nearend.1day.NPJC-PGEN 5760 (count) 0 - 691200000
STM1.pmthresholds.path.nearend.1day.PJCDIFF 5760 (count) 0 - 1382400000
STM1.pmthresholds.path.nearend.1day.PJCS-PDET 9600 (seconds) 0 - 86400
STM1.pmthresholds.path.nearend.1day.PJCS-PGEN 9600 (seconds) 0 - 86400
STM1.pmthresholds.path.nearend.1day.PPJC-PDET 5760 (count) 0 - 691200000
STM1.pmthresholds.path.nearend.1day.PPJC-PGEN 5760 (count) 0 - 691200000
STM1.pmthresholds.path.nearend.1day.SES 7 (seconds) 0 - 86400
STM1.pmthresholds.path.nearend.1day.UAS 10 (seconds) 0 - 86400
STM1.pmthresholds.rs.nearend.15min.BBE 10000 (count) 0 - 138600
STM1.pmthresholds.rs.nearend.15min.EB 10000 (count) 0 - 138600
STM1.pmthresholds.rs.nearend.15min.ES 500 (seconds) 0 - 900
STM1.pmthresholds.rs.nearend.15min.SEFS 500 (seconds) 0 - 900
STM1.pmthresholds.rs.nearend.15min.SES 500 (seconds) 0 - 900
STM1.pmthresholds.rs.nearend.15min.UAS 3 (seconds) 0 - 900
STM1.pmthresholds.rs.nearend.1day.BBE 100000 (count) 0 - 13305600
STM1.pmthresholds.rs.nearend.1day.EB 100000 (count) 0 - 13305600
STM1.pmthresholds.rs.nearend.1day.ES 5000 (seconds) 0 - 86400
STM1.pmthresholds.rs.nearend.1day.SEFS 5000 (seconds) 0 - 86400
STM1.pmthresholds.rs.nearend.1day.SES 5000 (seconds) 0 - 86400
STM1.pmthresholds.rs.nearend.1day.UAS 10 (seconds) 0 - 86400
Table C-7 STM-1 Card Default Settings (continued)
Default Name Default Value Default Domain
Table C-8 STM1-8 Card Default Settings
Default Name Default Value Default Domain
STM1-8.config.line.AdminSSMIn STU G811, STU, G812T, G812L, SETS, DUS
STM1-8.config.line.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
STM1-8.config.line.AlsMode Disabled Disabled, Auto Restart, Manual Restart,
Manual Restart for Test
STM1-8.config.line.AlsRecoveryPulseDuration 2.0 (seconds) 2.0, 2.1, 2.2 .. 100.0 when AlsMode
Disabled, Auto Restart, Manual Restart;
80.0, 80.1, 80.2 .. 100.0 when AlsMode
Manual Restart for Test
STM1-8.config.line.AlsRecoveryPulseInterval 100 (seconds) 60 - 300
STM1-8.config.line.PJVC4Mon# 0 (VC4 #) 0 - 1
