C-14
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
C.2.3.6 Ethernet Card Default Settings
Table C-6 lists the CE-100T-8, G1000 (G1K-4), ML-100T-12, ML-100X-8, and ML-1000-2 card default
settings.
STM1E-12.pmthresholds.rs.nearend.15min.EB 10000 (count) 0 - 138600
STM1E-12.pmthresholds.rs.nearend.15min.ES 500 (seconds) 0 - 900
STM1E-12.pmthresholds.rs.nearend.15min.SEFS 500 (seconds) 0 - 900
STM1E-12.pmthresholds.rs.nearend.15min.SES 500 (seconds) 0 - 900
STM1E-12.pmthresholds.rs.nearend.15min.UAS 3 (seconds) 0 - 900
STM1E-12.pmthresholds.rs.nearend.1day.BBE 100000 (count) 0 - 13305600
STM1E-12.pmthresholds.rs.nearend.1day.EB 100000 (count) 0 - 13305600
STM1E-12.pmthresholds.rs.nearend.1day.ES 5000 (seconds) 0 - 86400
STM1E-12.pmthresholds.rs.nearend.1day.SEFS 5000 (seconds) 0 - 86400
STM1E-12.pmthresholds.rs.nearend.1day.SES 5000 (seconds) 0 - 86400
STM1E-12.pmthresholds.rs.nearend.1day.UAS 10 (seconds) 0 - 86400
Table C-5 STM1E-12 Card Default Settings (continued)
Default Name Default Value Default Domain
Table C-6 Ethernet Card Default Settings
Default Name Default Value Default Domain
CE-1000-4.config.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
CE-1000-4.config.State locked, disabled unlocked, locked, disabled, locked, maintenance,
unlocked, automaticInService
CE-1000-4.etherPortConfig.AutoNegotiation TRUE TRUE, FALSE
CE-1000-4.etherPortConfig.FlowControl Symmetric None, Symmetric, Pass Through
CE-1000-4.etherPortConfig.MTU 10004 (bytes) 1548, 10004
CE-1000-4.posPortConfig.FramingType GFP-F HDLC, GFP-F
CE-100T-8.config.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
CE-100T-8.config.State locked, disabled unlocked, locked, disabled, locked, maintenance,
unlocked, automaticInService
CE-100T-8.etherPortConfig.802-1Q-VlanCoS 7 (count) 0 - 7
CE-100T-8.etherPortConfig.IP-ToS 255 (count) 0 - 255
G1000.config.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
G1000.config.State locked, disabled unlocked, locked, disabled, locked, maintenance,
unlocked, automaticInService
ML1000.config.card.Mode HDLC HDLC, GFP-F
ML1000.ios.consolePortAccess TRUE TRUE, FALSE
ML1000.ios.radiusServerAccess FALSE TRUE, FALSE
ML100T.config.card.Mode HDLC HDLC, GFP-F
