C-12
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
C.2.3.5 STM1E-12 Card Default Settings
Table C-5 lists the STM1E-12 card default settings.
DS3I.pmthresholds.vclo.nearend.15min.ES 12 (seconds) 0 - 900
DS3I.pmthresholds.vclo.nearend.15min.SES 3 (seconds) 0 - 900
DS3I.pmthresholds.vclo.nearend.15min.UAS 10 (seconds) 0 - 900
DS3I.pmthresholds.vclo.nearend.1day.BBE 150 (count) 0 - 207273600
DS3I.pmthresholds.vclo.nearend.1day.EB 125 (count) 0 - 691200000
DS3I.pmthresholds.vclo.nearend.1day.ES 100 (seconds) 0 - 86400
DS3I.pmthresholds.vclo.nearend.1day.SES 7 (seconds) 0 - 86400
DS3I.pmthresholds.vclo.nearend.1day.UAS 10 (seconds) 0 - 86400
Table C-4 DS3i-N-12 Card Default Settings (continued)
Default Name Default Value Default Domain
Table C-5 STM1E-12 Card Default Settings
Default Name Default Value Default Domain
STM1E-12.config.line.AdminSSMIn STU G811, STU, G812T, G812L, SETS, DUS
STM1E-12.config.line.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
STM1E-12.config.line.PJVC4Mon# 0 (VC4 #) 0 - 1
STM1E-12.config.line.SDBER 1.00E-07 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
STM1E-12.config.line.Send<FF>DoNotUse FALSE FALSE when SendDoNotUse TRUE;
FALSE, TRUE when SendDoNotUse
FALSE
STM1E-12.config.line.SendDoNotUse FALSE FALSE, TRUE
STM1E-12.config.line.SFBER 1.00E-04 1E-3, 1E-4, 1E-5
STM1E-12.config.line.State unlocked,
automaticInServic
e
unlocked, locked, disabled, locked,
maintenance, unlocked,
automaticInService
STM1E-12.config.line.SyncMsgIn TRUE FALSE, TRUE
STM1E-12.config.vc4.IPPMEnabled FALSE TRUE, FALSE
STM1E-12.pmthresholds.ms.farend.15min.BBE 1312 (count) 0 - 137700
STM1E-12.pmthresholds.ms.farend.15min.EB 1312 (count) 0 - 137700
STM1E-12.pmthresholds.ms.farend.15min.ES 87 (seconds) 0 - 900
STM1E-12.pmthresholds.ms.farend.15min.SES 1 (seconds) 0 - 900
STM1E-12.pmthresholds.ms.farend.15min.UAS 3 (seconds) 0 - 900
STM1E-12.pmthresholds.ms.farend.1day.BBE 13120 (count) 0 - 13219200
STM1E-12.pmthresholds.ms.farend.1day.EB 13120 (count) 0 - 13219200
STM1E-12.pmthresholds.ms.farend.1day.ES 864 (seconds) 0 - 86400
STM1E-12.pmthresholds.ms.farend.1day.SES 4 (seconds) 0 - 86400
