C-11
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
DS3I.pmthresholds.pbitpath.nearend.1day.ES 250 (seconds) 0 - 86400
DS3I.pmthresholds.pbitpath.nearend.1day.SAS 8 (seconds) 0 - 86400
DS3I.pmthresholds.pbitpath.nearend.1day.SES 40 (seconds) 0 - 86400
DS3I.pmthresholds.pbitpath.nearend.1day.UAS 10 (seconds) 0 - 86400
DS3I.pmthresholds.vc4.farend.15min.BBE 25 (count) 0 - 2159100
DS3I.pmthresholds.vc4.farend.15min.EB 15 (count) 0 - 7200000
DS3I.pmthresholds.vc4.farend.15min.ES 12 (seconds) 0 - 900
DS3I.pmthresholds.vc4.farend.15min.SES 3 (seconds) 0 - 900
DS3I.pmthresholds.vc4.farend.15min.UAS 10 (seconds) 0 - 900
DS3I.pmthresholds.vc4.farend.1day.BBE 250 (count) 0 - 207273600
DS3I.pmthresholds.vc4.farend.1day.EB 125 (count) 0 - 691200000
DS3I.pmthresholds.vc4.farend.1day.ES 100 (seconds) 0 - 86400
DS3I.pmthresholds.vc4.farend.1day.SES 7 (seconds) 0 - 86400
DS3I.pmthresholds.vc4.farend.1day.UAS 10 (seconds) 0 - 86400
DS3I.pmthresholds.vc4.nearend.15min.BBE 25 (count) 0 - 2159100
DS3I.pmthresholds.vc4.nearend.15min.EB 15 (count) 0 - 7200000
DS3I.pmthresholds.vc4.nearend.15min.ES 12 (seconds) 0 - 900
DS3I.pmthresholds.vc4.nearend.15min.SES 3 (seconds) 0 - 900
DS3I.pmthresholds.vc4.nearend.15min.UAS 10 (seconds) 0 - 900
DS3I.pmthresholds.vc4.nearend.1day.BBE 250 (count) 0 - 207273600
DS3I.pmthresholds.vc4.nearend.1day.EB 125 (count) 0 - 691200000
DS3I.pmthresholds.vc4.nearend.1day.ES 100 (seconds) 0 - 86400
DS3I.pmthresholds.vc4.nearend.1day.SES 7 (seconds) 0 - 86400
DS3I.pmthresholds.vc4.nearend.1day.UAS 10 (seconds) 0 - 86400
DS3I.pmthresholds.vclo.farend.15min.BBE 15 (count) 0 - 2159100
DS3I.pmthresholds.vclo.farend.15min.EB 15 (count) 0 - 7200000
DS3I.pmthresholds.vclo.farend.15min.ES 12 (seconds) 0 - 900
DS3I.pmthresholds.vclo.farend.15min.SES 3 (seconds) 0 - 900
DS3I.pmthresholds.vclo.farend.15min.UAS 10 (seconds) 0 - 900
DS3I.pmthresholds.vclo.farend.1day.BBE 150 (count) 0 - 207273600
DS3I.pmthresholds.vclo.farend.1day.EB 125 (count) 0 - 691200000
DS3I.pmthresholds.vclo.farend.1day.ES 100 (seconds) 0 - 86400
DS3I.pmthresholds.vclo.farend.1day.SES 7 (seconds) 0 - 86400
DS3I.pmthresholds.vclo.farend.1day.UAS 10 (seconds) 0 - 86400
DS3I.pmthresholds.vclo.nearend.15min.BBE 15 (count) 0 - 2159100
DS3I.pmthresholds.vclo.nearend.15min.EB 15 (count) 0 - 7200000
Table C-4 DS3i-N-12 Card Default Settings (continued)
Default Name Default Value Default Domain
