C-10
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
DS3I.config.State unlocked,
automaticInService
unlocked, locked, disabled, locked,
maintenance, unlocked, automaticInService
DS3I.pmthresholds.cpbitpath.farend.15min.CV 382 (count) 0 - 287100
DS3I.pmthresholds.cpbitpath.farend.15min.ES 25 (seconds) 0 - 900
DS3I.pmthresholds.cpbitpath.farend.15min.SAS 2 (seconds) 0 - 900
DS3I.pmthresholds.cpbitpath.farend.15min.SES 4 (seconds) 0 - 900
DS3I.pmthresholds.cpbitpath.farend.15min.UAS 10 (seconds) 0 - 900
DS3I.pmthresholds.cpbitpath.farend.1day.CV 3820 (count) 0 - 27561600
DS3I.pmthresholds.cpbitpath.farend.1day.ES 250 (seconds) 0 - 86400
DS3I.pmthresholds.cpbitpath.farend.1day.SAS 8 (seconds) 0 - 86400
DS3I.pmthresholds.cpbitpath.farend.1day.SES 40 (seconds) 0 - 86400
DS3I.pmthresholds.cpbitpath.farend.1day.UAS 10 (seconds) 0 - 86400
DS3I.pmthresholds.cpbitpath.nearend.15min.CV 382 (count) 0 - 287100
DS3I.pmthresholds.cpbitpath.nearend.15min.ES 25 (seconds) 0 - 900
DS3I.pmthresholds.cpbitpath.nearend.15min.SES 4 (seconds) 0 - 900
DS3I.pmthresholds.cpbitpath.nearend.15min.UAS 10 (seconds) 0 - 900
DS3I.pmthresholds.cpbitpath.nearend.1day.CV 3820 (count) 0 - 27561600
DS3I.pmthresholds.cpbitpath.nearend.1day.ES 250 (seconds) 0 - 86400
DS3I.pmthresholds.cpbitpath.nearend.1day.SES 40 (seconds) 0 - 86400
DS3I.pmthresholds.cpbitpath.nearend.1day.UAS 10 (seconds) 0 - 86400
DS3I.pmthresholds.line.nearend.15min.CV 387 (BPV count) 0 - 38700
DS3I.pmthresholds.line.nearend.15min.ES 25 (seconds) 0 - 900
DS3I.pmthresholds.line.nearend.15min.LOSS 10 (seconds) 0 - 900
DS3I.pmthresholds.line.nearend.15min.SES 4 (seconds) 0 - 900
DS3I.pmthresholds.line.nearend.1day.CV 3865 (BPV count) 0 - 3715200
DS3I.pmthresholds.line.nearend.1day.ES 250 (seconds) 0 - 86400
DS3I.pmthresholds.line.nearend.1day.LOSS 10 (seconds) 0 - 86400
DS3I.pmthresholds.line.nearend.1day.SES 40 (seconds) 0 - 86400
DS3I.pmthresholds.pbitpath.nearend.15min.AISS 10 (seconds) 0 - 900
DS3I.pmthresholds.pbitpath.nearend.15min.CV 382 (count) 0 - 287100
DS3I.pmthresholds.pbitpath.nearend.15min.ES 25 (seconds) 0 - 900
DS3I.pmthresholds.pbitpath.nearend.15min.SAS 2 (seconds) 0 - 900
DS3I.pmthresholds.pbitpath.nearend.15min.SES 4 (seconds) 0 - 900
DS3I.pmthresholds.pbitpath.nearend.15min.UAS 10 (seconds) 0 - 900
DS3I.pmthresholds.pbitpath.nearend.1day.AISS 10 (seconds) 0 - 86400
DS3I.pmthresholds.pbitpath.nearend.1day.CV 3820 (count) 0 - 27561600
Table C-4 DS3i-N-12 Card Default Settings (continued)
Default Name Default Value Default Domain
