C-9
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
C.2.3.4 DS3i-N-12 Card Default Settings
Table C-4 lists the DS3i-N-12 card default settings.
E3.pmthresholds.vc4.nearend.1day.ES 100 (seconds) 0 - 86400
E3.pmthresholds.vc4.nearend.1day.SES 7 (seconds) 0 - 86400
E3.pmthresholds.vc4.nearend.1day.UAS 10 (seconds) 0 - 86400
E3.pmthresholds.vclo.farend.15min.BBE 15 (count) 0 - 2159100
E3.pmthresholds.vclo.farend.15min.EB 15 (count) 0 - 7200000
E3.pmthresholds.vclo.farend.15min.ES 12 (seconds) 0 - 900
E3.pmthresholds.vclo.farend.15min.SES 3 (seconds) 0 - 900
E3.pmthresholds.vclo.farend.15min.UAS 10 (seconds) 0 - 900
E3.pmthresholds.vclo.farend.1day.BBE 150 (count) 0 - 207273600
E3.pmthresholds.vclo.farend.1day.EB 125 (count) 0 - 691200000
E3.pmthresholds.vclo.farend.1day.ES 100 (seconds) 0 - 86400
E3.pmthresholds.vclo.farend.1day.SES 7 (seconds) 0 - 86400
E3.pmthresholds.vclo.farend.1day.UAS 10 (seconds) 0 - 86400
E3.pmthresholds.vclo.nearend.15min.BBE 15 (count) 0 - 2159100
E3.pmthresholds.vclo.nearend.15min.EB 15 (count) 0 - 7200000
E3.pmthresholds.vclo.nearend.15min.ES 12 (seconds) 0 - 900
E3.pmthresholds.vclo.nearend.15min.SES 3 (seconds) 0 - 900
E3.pmthresholds.vclo.nearend.15min.UAS 10 (seconds) 0 - 900
E3.pmthresholds.vclo.nearend.1day.BBE 150 (count) 0 - 207273600
E3.pmthresholds.vclo.nearend.1day.EB 125 (count) 0 - 691200000
E3.pmthresholds.vclo.nearend.1day.ES 100 (seconds) 0 - 86400
E3.pmthresholds.vclo.nearend.1day.SES 7 (seconds) 0 - 86400
E3.pmthresholds.vclo.nearend.1day.UAS 10 (seconds) 0 - 86400
Table C-3 E3-12 Card Default Settings (continued)
Default Name Default Value Default Domain
Table C-4 DS3i-N-12 Card Default Settings
Default Name Default Value Default Domain
DS3I.config.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
DS3I.config.FeInhibitLpbk FALSE TRUE, FALSE
DS3I.config.LineLength 0 - 225 ft 0 - 225 ft, 226 - 450 ft
DS3I.config.LineType C BIT UNFRAMED, M13, C BIT, AUTO
PROVISION FMT
DS3I.config.SDBER 1.00E-07 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
DS3I.config.SFBER 1.00E-04 1E-3, 1E-4, 1E-5
