C-8
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
Table C-3 E3-12 Card Default Settings
Default Name Default Value Default Domain
E3.config.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
E3.config.SDBER 1.00E-07 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
E3.config.SFBER 1.00E-04 1E-3, 1E-4, 1E-5
E3.config.State unlocked,
automaticInService
unlocked, locked, disabled, locked, maintenance,
unlocked, automaticInService
E3.pmthresholds.line.nearend.15min.CV 387 (BPV count) 0 - 38700
E3.pmthresholds.line.nearend.15min.ES 25 (seconds) 0 - 900
E3.pmthresholds.line.nearend.15min.LOSS 10 (seconds) 0 - 900
E3.pmthresholds.line.nearend.15min.SES 4 (seconds) 0 - 900
E3.pmthresholds.line.nearend.1day.CV 3865 (BPV count) 0 - 3715200
E3.pmthresholds.line.nearend.1day.ES 250 (seconds) 0 - 86400
E3.pmthresholds.line.nearend.1day.LOSS 10 (seconds) 0 - 86400
E3.pmthresholds.line.nearend.1day.SES 40 (seconds) 0 - 86400
E3.pmthresholds.path.nearend.15min.ES 20 (seconds) 0 - 900
E3.pmthresholds.path.nearend.15min.SES 3 (seconds) 0 - 900
E3.pmthresholds.path.nearend.15min.UAS 10 (seconds) 0 - 900
E3.pmthresholds.path.nearend.1day.ES 200 (seconds) 0 - 86400
E3.pmthresholds.path.nearend.1day.SES 7 (seconds) 0 - 86400
E3.pmthresholds.path.nearend.1day.UAS 10 (seconds) 0 - 86400
E3.pmthresholds.vc4.farend.15min.BBE 25 (count) 0 - 2159100
E3.pmthresholds.vc4.farend.15min.EB 15 (count) 0 - 7200000
E3.pmthresholds.vc4.farend.15min.ES 12 (seconds) 0 - 900
E3.pmthresholds.vc4.farend.15min.SES 3 (seconds) 0 - 900
E3.pmthresholds.vc4.farend.15min.UAS 10 (seconds) 0 - 900
E3.pmthresholds.vc4.farend.1day.BBE 250 (count) 0 - 207273600
E3.pmthresholds.vc4.farend.1day.EB 125 (count) 0 - 691200000
E3.pmthresholds.vc4.farend.1day.ES 100 (seconds) 0 - 86400
E3.pmthresholds.vc4.farend.1day.SES 7 (seconds) 0 - 86400
E3.pmthresholds.vc4.farend.1day.UAS 10 (seconds) 0 - 86400
E3.pmthresholds.vc4.nearend.15min.BBE 25 (count) 0 - 2159100
E3.pmthresholds.vc4.nearend.15min.EB 15 (count) 0 - 7200000
E3.pmthresholds.vc4.nearend.15min.ES 12 (seconds) 0 - 900
E3.pmthresholds.vc4.nearend.15min.SES 3 (seconds) 0 - 900
E3.pmthresholds.vc4.nearend.15min.UAS 10 (seconds) 0 - 900
E3.pmthresholds.vc4.nearend.1day.BBE 250 (count) 0 - 207273600
E3.pmthresholds.vc4.nearend.1day.EB 125 (count) 0 - 691200000
